Attributes

Ship via: Can Ship UPS

Adjustability: Horizontal

Amp Draw: .24 Amps at 12VDC, .12 Amps at 24VDC

Complete Pack Options: CS- includes 1LB faceplate kit for Latchbolts and 1DB faceplate kit for Deadbolts

Dynamic Strength (ft-lbs): 70

Endurance (cycles): 1,000,000

Face Shape: Flat Face, Square Corners

Faceplate Size: 4-7/8 In. X 1-1/4 In.

Fail Safe | Fail Secure: Field selectable fail safe/fail secure

Finish: 612 Satin bronze, clear coated

Finish Description: Satin Bronze Clear Coated

Fire Rated: Yes

Frame Application: Metal or Wood

Frame Depth: 1-5/8 In.

Frame Material: Metal|Wood

Function: Field Selectable (Safe/Secure)

Grade: Grade 1

Handing: Non-handed

Latchbolt Accommodation: 3/4" - 1"

Limited Warranty: 1 Year

Lock Type: Cylindrical Lock|Mortise Lock|Mortise Lock with Deadbolt

Monitoring Installation: Factory Configured|Field Installable

Monitoring Options: Dual Lock Monitors|Lock Monitor

Operating Voltage: 12VDC/24VDC

Series: 1600 Series

Shim Type: Field Adjustable

Static Strength (lbs): 1500

Subtype: Electric Strikes

Surface Mounting: Cutting required

Switch Type: None

Tamper Resistant: Yes

Type: Electronics

Use With: Cylindrical and Mortise Latchbolts and Deadbolts

Voltage: 12/24
