IEI PIP24VDCRU Plug in Power Supply 1000mA

IEI PIP24VDCRU Plug-in Power Supply 1000mA is an essential component for any security system, providing reliable power in a compact design. This EISA compliant power supply operates on a 120 VAC input and delivers a steady 24 VDC output at 1000 mA (1 amp) maximum, ensuring compatibility with a wide range of applications. With its output voltage regulated within ±1% from 0% to 100% load, the PIP24VDCRU is versatile enough for both low-load and high-load setups. The built-in auto-resetting poly fuse enhances reliability by preventing unnecessary service calls after a short circuit. Ground protection is included with a ground prong on the AC power input and a ground output terminal, making it easy to connect to your panel. Robust surge protection safeguards your equipment from AC line spikes and transients, while a red LED power indicator allows for quick visual confirmation of operation. Designed for convenience, this power supply plugs directly into an AC outlet, featuring a knockout for a wall outlet retaining screw, simplifying installation. Measuring just 2.5" W x 3.5" H x 2.25" D, the IEI PIP24VDCRU is a space-efficient solution that combines transformer and power supply functions in one unit, making it an ideal choice for your access control and security needs.

Plug in Power Supply 1000mA

Plug-in power supply, EISA compliant, auto-resetting poly fuse, 120 VAC input, 24 VDC output @ 1000 mA (1 amp) maximum.

Features:

• Output voltage regulated at ±1% from 0% to 100% load, expands options for use in low-load and high-load applications
• Poly-fuse automatically resets after a short circuit, prevents unnecessary service calls
• Ground prong on AC power input and ground output terminal, provides input protection and easy panel ground connection
• Robust surge protection, prevents AC line spikes and transients from harming the power supply or the connected equipment
• Red LED power indicator, shows at a glance that the supply is operating
• Plugs directly into AC outlet, knockout for wall outlet retaining screw, easy and quick to install
• Acts as transformer and power supply in-one, no cabinet to mount
• Dimensions: 2.5" W x 3.5" H x 2.25" D

Resources

• Cut Sheet
