LCN 4040XP-H LH 651 Heavy Duty Surface Closer US26 offers exceptional durability and versatility, making it the ideal choice for high-traffic and institutional applications. This Grade 1 surface door closer features a hold-open arm and can be mounted on either the push or pull side, accommodating a generous 120-degree swing. With adjustable sizing from 1 to 6, it provides a tailored solution for various door sizes, including interior doors up to 5'0" and exterior doors up to 4'0". Engineered with a robust design, the LCN 4040XP boasts a 44% increased bearing load capacity and the strongest pinion ever created, ensuring reliability and longevity. The innovative V-shield™ seal extends the closer’s lifespan by 20%, while the all-weather fluid guarantees performance regardless of conditions. This non-handed closer is UL and cUL listed, meeting rigorous ANSI A156.4 standards for self-closing doors. Installation is fast and precise, thanks to LCN® Fast™ Power Adjust technology. The metal cover is finished in a polished silver, enhancing its aesthetic appeal while protecting against wear. With a 30-year limited warranty, the LCN 4040XP offers unmatched value and peace of mind for commercial settings.
Heavy Duty Surface Closer US26
Grade 1 Surface Door Closer, Hold Open Arm, Push or Pull Side Mounting, 120 Degree Swing, Adjustable Size 1-6, Metal Cover, Bright Chromium Plated Finish, Left-Handed
LCN's most durable and flexible heavy duty closer designed for institutional and other demanding high traffic applications.
Durable, non-handed, heavy duty closer designed for the most demanding, high-use and abuse applications.
The LCN 4040XP sets a new standard for reliability, longevity and value with a beefier design and extraordinary performance testing that goes far beyond industry requirements. LCN built the 4040XP from the inside out, combining tougher, bolder construction with proven LCN technology. The result is a closer that’s stronger, smarter and delivers remarkable value in a variety of applications.
Accessible: Yes
Ada Compliance: Yes
Ansi: A156.4
Arm Type: Regular Hold Open Arm
Baa Qualified: Yes
Back Check: Adjustable
Base Material: Brass or Bronze
Closer Size: 1 to 6
Cold Weather Fluid: Yes
Commercial Residential: Commercial
Country of origin: USA
Cover: Metal
Degree Hold Open: Adjustable
Degree Swing: 120 Deg.
Delay: No
Finish: 625/US26
Finish Family: Polished Silver
Fire Rated: 3 Hours {A}
Fire Rating: 3 Hours {A}
Grade: Grade 1
Handing: Left-Handed
Hold Open: Yes
Hold Open Type: Friction
Installation: Commercial
Limited Warranty: 30 Years
Mounting Group: Hydraulic
Mounting Location: Push or Pull Side
Mounting Style: Regular
Origin: USA
Pack Height: 5.75"
Pack Height 2: 9.25"
Pack Length: 16"
Pack Length 2: 16.5"
Pack Qty: 1
Pack Volume: 391 in³
Pack Volume 2: 1907.81 in³
Pack Width: 4.25"
Pack Width 2: 12.5"
Product Height: 3.75"
Product Length: 12"
Product Width: 2.25"
Screw Type: Self-Tapping
Series: 4040XP Series Surface Mounted Closers
Ship Weight: 11.7 lbs.
Subtype: Surface Closers
Through Bolts: No
Type: Surface
Ul Listing: UL 10C
Unit of Measure: Each
Unit of Measure 2: Case
Unit of Measure 2 Qty: 4
