Little Giant 554435 115V Condensate Removal Pump with Safety Switch TubingLittle Giant 554435 115V Condensate Removal Pump with Safety Switch Tubing offers reliable performance for efficient condensate management in residential and commercial settings. Designed with a high-performance 1/30 horsepower motor, this pump effectively handles condensate from furnaces, air conditioning units, and other appliances, ensuring a smooth and hassle-free operation. Constructed from durable ABS material, the pump features a ½-gallon tank capacity and a robust motor cover and volute, providing longevity and resistance to wear. The stainless steel shaft adds to its durability, while the thermal overload protection ensures safe operation, preventing overheating and potential damage. The pump’s design includes three inlet drain holes, optimizing fluid intake for efficient performance. With a flow rate of 80 gallons per hour and a maximum head of 20 feet, the Little Giant pump is engineered to handle demanding applications effortlessly. The removable 3/8" barbed check valve allows for easy maintenance and compatibility with various plumbing configurations. Additionally, the 6-foot cord length provides flexibility in installation, making it suitable for a variety of spaces. Measuring 11 inches in length, 5 inches in width, and 7.3 inches in height, this compact unit can be mounted vertically, fitting seamlessly into tight areas. The CSA listing assures compliance with safety standards, while the double insulated, enclosed motor housing enhances its reliability. Choose the Little Giant 554435 Condensate Removal Pump for its blend of innovative design and proven durability, ensuring efficient performance for all your condensate removal needs.
115V Condensate Removal Pump with Safety Switch Tubing
AUTOMATIC CONDENSATE PUMP: features a vertical-type switch to reduce footprint and is designed to automatically remove condensate produced by boilers, furnaces, air conditioners and de-humidifiers
HIGH PERFORMANCE MOTOR: 1/30 HP, 1.5 Amps, 93 Watts, 115 Volts, 60 Hz, thermally protected, fan-cooled motor; CSA listed in the USA and Canada
BUILT TO LAST: stainless steel motor shaft, thermal overload protected motor; CSA certified to US and Canadian standards
INCLUDES SAFETY SWITCH and 20-FT VINYL TUBING: safety switch can be connected to shut down the air conditioner condenser or wired to an alarm to warn of possible tank overflow
SPECIFICATIONS: 3/8-inch OD barbed discharge, 80 GPH at 1-foot head, 20 foot shut-off, up to 8.7 PSI, 3 inlet drain holes, 6-foot cord; maximum water temperature: 140 F, equipped with safety switch, 20-ft. tubing included
Three inlet drain holes
Thermal overload protection
CSA listed
Double insulated, enclosed motor housing
Attributes
AMP: 1.5
Collection: VCMA-20 Series
Connection Type: Barbed
Cord Length: 6 ft
Depth: 11 in
Discharge: 3/8 in
End Connection 1: Barbed
End Connection 2: Barbed
End Connections: Barbed
Flow Rate: 80 gph
Frequency: 60
Height: 7 in
Horsepower: 1/30 hp
Impeller: Polypropylene
Length: 11 in
Maximum Feet of Head: 20
Origin: Global
Power Source: Electric
Proposition 65: WARNING: Cancer - www.P65Warnings.ca.gov
Pump Application: Furnaces
Pump Body Material: Plastic
Pump Mounting: Vertical
UL Listed: No
Upc: 010121544352
Volts: 115V
Watts: 93 W
Width: 5 in
