Morris 23179 Color-Coded Screw-On Wire Connectors for Quick Connections

Morris 23179 Screw-On Wire Connectors offer a reliable solution for quick and efficient electrical connections. Designed with a fixed precise conical wire spring, these connectors eliminate the need for pre-twisting of conductors, allowing the spring to create its own thread for effortless installation. This feature is particularly beneficial for professionals needing to make fast circuit changes and additions, as the reusable screw-on design allows for easy threading on and off. Constructed with a tough, UL 94V-2 flame-retardant shell, these connectors are built to withstand extreme pressure without cracking or breaking. The ribbed cap ensures a secure grip, enabling quick fingertip starts even when your hands are slippery. Added protection is provided by the deep skirt wire entry, which safeguards against flash-overs and shorts, while the threaded funnel entry guides wires into the connector cleanly, preventing strand splaying. With a temperature rating of 221°F (105°C) and a maximum voltage capacity of 300V, the Morris 23179 connectors are cULus listed for safety and reliability. Packaged in bulk pails, they are ideal for contractors and DIY enthusiasts looking for quality wire connectors that deliver performance and peace of mind.

Screw-On Wire Connectors - Color-Coded Screw On Wire Connectors for quick connections anytime.

• Threaded Funnel Entry Guides Wire Into Connector Cleanly without Strand Splaying
• Deep Skirt Wire Entry Provides Protection from Flash-Over and Shorts
• cULus Listed
• Fixed Precise Conical Wire Spring
• Ribbed-Cap Provides a more Secure Grip and faster fingertip starts even when hands become slippery
• No Pre-Twisting of Conductors is Required – Spring Creates its Own Thread
• Reusable Screw on Wire Connector Threads On or Off splice for fast and easy circuit changes and additions
• Tough, UL 94V-2 Flame Retardant Shell will not crack or break, even when applied to maximum wire combinations under extreme pressure
• Temperature Rated at 221°F (105°C) maximum
