Morris 70070 Heavy Duty On-Off Double Toggle Switch for Motor Control Tools

Morris 70070 heavy-duty On-Off Double Toggle Switch is an essential component for motor control, tools, and various equipment applications. Engineered for durability and performance, this switch features solid brass or nickel-plated bushings, ensuring reliable conductivity and resilience in demanding environments. With a compact design measuring 1.13" x 0.63" x 0.67", the Morris 70070 is equipped with a 1/2" mounting hole for easy installation. Its dielectric strength of 1500V guarantees safe operation, while the mechanical life cycle rating of 100,000 cycles ensures longevity, making it a dependable choice for both residential and commercial settings. Operating effectively in temperatures ranging from 32°F to 185°F, this SPST (Single Pole Single Throw) switch supports a standard load rating of 20 AMP at 125VAC and 10 AMP at 277VAC. It can also manage motor loads of up to 3/4HP at both 125VAC and 250VAC, providing flexibility for various applications. The switch features two screw terminals for straightforward connections. cURus listed for safety, the Morris 70070 On-Off Double Toggle Switch is a reliable choice for professionals seeking high-quality electrical components. Please note the warning regarding cancer and reproductive harm, which is important for safe handling and installation.

Our heavy duty On-Off Double Toggle Switch is used in Motor Control, Tool and other Equipment Applications.

• cURus Listed
• Mechanical Life Cycles: 100,000
• 2 Screw Terminals
• 1/2" Mounting Hole
• SPST, ON-OFF
• Operating Temperature: 32°F to 185°F
• Dielectric Strength: 1500V
• 20 AMP, 125VAC
• 10 AMP, 277VAC
• Solid Brass or Nickel Plated Bushings
• 3/4HP, 125/250VAC
