Morris 70280 Heavy Duty Momentary Double Toggle Switch for Motor Control Tools

Morris 70280 is a heavy-duty momentary double toggle switch designed specifically for motor control tool applications. With its reliable SPDT configuration and three screw terminals, this switch ensures efficient operation while handling demanding electrical loads. It boasts an impressive load capacity of 20 amps at 125VAC and 10 amps at 277VAC, making it suitable for various setups. The Morris 70280 features solid brass or nickel-plated bushings, enhancing durability and providing excellent conductivity. It fits snugly into a 1/2-inch mounting hole, allowing for easy installation in a variety of environments. With a dielectric strength of 1500V, this switch is built to withstand high voltage conditions, ensuring safety and performance. Designed for longevity, the mechanical life cycles of up to 100,000 guarantee that this switch will stand the test of time, while its operating temperature range of 32°F to 185°F ensures versatility across different climates. Additionally, the switch is cURus listed, providing peace of mind regarding safety and compliance. Whether for residential, commercial, or industrial use, the Morris 70280 momentary double toggle switch is a reliable choice for professionals seeking quality and performance in their electrical components.

This heavy duty Momentary Double Toggle Switch is used in Motor Control & Tool Applications.

• cURus Listed
• Mechanical Life Cycles: 100,000
• Momentary = ( )
• 3 Screw Terminals
• 3/4HP 125/250VAC
• SPDT
• 1/2" Mounting Hole
• Operating Temperature: 32°F to 185°F
• 20 AMP, 125VAC
• 10 AMP, 277VAC
• Dielectric Strength: 1500V
• Solid Brass or Nickel Plated Bushings
