Morris 94852 One Hole Copper Compression Lugs deliver fast and reliable electrical cable terminations, making them an essential choice for electrical professionals. Crafted from high-conductivity seamless electrolytic copper, these lugs ensure maximum conductivity and performance in various applications. The uniform bright electro-tin plating offers superior corrosion resistance, effectively reducing contact resistance and enhancing electrical flow. Designed with a single mounting hole, the Morris 94852 features crimp marks that indicate proper crimp locations, simplifying installation. Each lug is marked with die index and color codes for easy identification, ensuring you always choose the right component for your project. The long barrel design accommodates multiple crimps, providing versatility and reliability in demanding environments. With a UL 486A listing and rated for up to 35KV when properly installed, these compression lugs meet stringent safety standards. Additional specifications include an inside diameter of .204 inches, an outside diameter of .297 inches, and a length of 2.01 inches, with a stud size of #8. Compatible with wire ranges of 6-stranded conductors, the Morris 94852 is the go-to choice for contractors seeking high-quality, dependable electrical components.
One Hole Copper Compression Lugs for fast reliable electrical cable terminations.
Barrel Length: Long
Color: Blue
Color Code: Blue
Connector Style: Lug
Connector Type: Compression
Country of Origin: India
Description: Copper Long Barrel 1 Hole Compression Lugs 6 Awg - #8 Stud
Finish: Electro-Tin Plated
Hole Size: #8
Inside Diameter: .204"
Length: 2.01"
Material: High Conductivity Copper
Maximum Voltage: 35KV
Mfg Standard: Ul 486A
Number of Mounting Holes: 1
Outside Diameter: .297"
Stud Size: #8
Type: Copper Long Barrel 1 Hole Compression Lugs
Ul Listing: cULus
Upc: 601986948524
Warning: Cancer and Reproductive Harm
Wire Range: 6 Str.
Wire Size: 9 Str.
