Morris 97105 Single Entry Insulated Connector makes splicing easy and secure, providing a reliable solution for your electrical needs. Designed for both copper and aluminum wires, this connector is constructed from robust 6061-T6 aluminum with a dual rating, ensuring versatility in various applications. The rugged high-dielectric rubber/vinyl coating offers excellent insulation, while the pre-filled oxide inhibitor helps maintain optimal conductivity. Each connector allows both wires to enter from the same side, facilitating straightforward splicing. For added convenience, the plugs are marked with the maximum wire size, ensuring quick identification during installation. This connector is engineered for indoor use only and supports a temperature range of –49°F to 194°F (–45° to 90°C), making it suitable for a variety of environments. Compliant with ANSI C119.4 and cULus 486b standards, the Morris 97105 can handle up to 600 volts and is rated for use with cables up to 194°F (90°C). With dimensions of 1.93" in height, 1.69" in length, and 1.80" in width, it fits seamlessly into your project. The wire range accommodates sizes from 1/0 to 14, making it a versatile choice for professionals and experienced homeowners alike.
Single Entry Insulated Connector makes splicing easy and secure.
Al9cu Dual Rating: AL9CU Dual Rated
Allen Hex: 3/16"
Color: Black
Connector Type: Single Entry
Country of Origin: India
Description: Black Insulated 2 Conductor Single Side Entry Splice 1/0 - 14
Height: 1.93"
Insulation Type: Rubber
Length: 1.69"
Material: 6061-T6 Aluminum
Maximum Voltage: 600
Mfg Standard: UL 486B
Number of Positions: 2
Temperature Rating: -49oF to 194oF (-45o to 90oC)
Type: Black 2 Conductor Single Side Entry Splice
Ul Listing: cULus
Upc: 601986971058
Warning: Cancer and Reproductive Harm
Width: 1.80"
Wire Range: 1/0 - 14
Wire Size: 1/0 - 14
