Morris 97106 Single Entry Insulated Connector makes splicing easy and secure, ensuring reliable connections for your electrical projects. Designed for professionals and knowledgeable homeowners alike, this connector allows both wires to enter from the same side, simplifying installation and minimizing complexity. Constructed from durable 6061-T6 aluminum and rated for use with both copper and aluminum wires, the Morris 97106 is a versatile solution for a variety of applications. The rugged high-dielectric rubber/vinyl coating provides excellent insulation, while the pre-filled oxide inhibitor enhances performance by preventing oxidation at the connection point. With a temperature range of -49°F to 194°F (-45°C to 90°C), this connector is rated for indoor use only and is suitable for cables rated up to 194°F (90°C) at 600 volts. Each plug is conveniently marked with the maximum wire size for quick identification, accommodating wire ranges from 2/0 to 6. The Morris 97106 also features easy re-entry for any necessary changes, inspections, or troubleshooting, making it an ideal choice for both new installations and maintenance. ANSI C119.4 and cULus 486b listed, it meets industry standards for safety and performance.
Single Entry Insulated Connector makes splicing easy and secure.
Al9cu Dual Rating: AL9CU Dual Rated
Allen Hex: 3/16"
Color: Black
Connector Type: Single Entry
Country of Origin: India
Description: Black Insulated 2 Conductor Single Side Entry Splice 2/0 - 6
Height: 1.93"
Insulation Type: Rubber
Length: 1.69"
Material: 6061-T6 Aluminum
Maximum Voltage: 600
Mfg Standard: UL 486B
Number of Positions: 2
Temperature Rating: -49oF to 194oF (-45o to 90oC)
Type: Black 2 Conductor Single Side Entry Splice
Ul Listing: cULus
Upc: 601986971065
Warning: Cancer and Reproductive Harm
Width: 1.80"
Wire Range: 2/0 - 6
Wire Size: 2/0 - 6
