Morris 97306 Clear In-Line Insulated Connector for Accurate Termination

Morris 97306 Clear In-Line Insulated Connector offers a reliable solution for ensuring your electrical terminations are consistently accurate. This innovative connector features clear insulation that allows for visual confirmation of proper conductor insertion, providing peace of mind during installation. Constructed from durable 6061-T6 aluminum, the dual-rated CU9AL connector is compatible with both copper and aluminum wire, making it a versatile choice for various applications. The single-piece clear molded insulation is not only rugged but also features a high-dielectric, plastisol-dipped coating that resists chemicals and abrasion. Designed for ease of use, the Morris 97306 includes removable plugs clearly marked with wire sizes, simplifying installation and re-entry for changes or troubleshooting. With a temperature range of -49°F to 194°F (-45°C to 90°C) and rated for 600 volts, this connector is suitable for indoor use only. The PVC insulation enhances safety by minimizing the risk of power outages caused by improper connections, while the pre-filled oxide inhibitor ensures long-term performance. Measuring 2.63 inches in height, 5.21 inches in length, and 1.33 inches in width, this connector accommodates wire ranges from 350 to 6. Upgrade your electrical projects with the reliability of the Morris 97306 Clear In-Line Insulated Connector.

With our Clear In-Line Insulated Connector, you'll see your termination is right every time

• Clear Insulation allows Visual Confirmation that conductor is properly inserted
• Indoor Use Only
• Easy Re-Entry for Changes, Inspection or Troubleshooting
• In-Line 6061-T6 Aluminum Connector - CU9AL Dual Rated for use with Copper and/or Aluminum wire
• Insulated aluminum connector eliminates the need for time consuming manual taping, reducing installation time
• PVC insulation reduces the likelihood & cost of power outages caused by improper or inconsistent insulated connections done manually in the field
• Rated for use with 194°F(90°C) Cables
• One Wire Per Terminal
• Removable Plugs marked with wire size provide easy access for installation.
• Single Piece Clear Molded Insulation with Rugged High-Dielectric Plastisol Dipped Coating is chemical and abrasion resistant
• Pre-filled with Oxide Inhibitor
• 600 Volt
• Wire entry from either end of clear connector
• Dimension Measurements = Inches
• Temperature range of –49°F to 194°F (–45° to 90°C)
• ANSI C119.4 & cULus 486b Listed
