Morris 97308 Clear In-Line Insulated Connector for Reliable Terminations

Morris 97308 Clear In-Line Insulated Connector offers a reliable solution for ensuring quality electrical connections. Designed with clear insulation, this connector allows for visual confirmation that conductors are properly inserted, enhancing installation confidence. Constructed from durable 6061-T6 aluminum, it is dual-rated for use with both copper and aluminum wires, accommodating various application needs. The single-piece clear molded insulation is coated with rugged high-dielectric Plastisol, making it resistant to chemicals and abrasion. Pre-filled with an oxide inhibitor, this connector provides long-lasting protection against corrosion. With easy re-entry features, inspections and troubleshooting are simplified, allowing for quick adjustments when necessary. Removable plugs marked with wire sizes facilitate user-friendly installation, while the insulated aluminum construction eliminates the need for time-consuming manual taping, significantly reducing installation time. Rated for up to 600 volts and compatible with cables up to 194°F (90°C), this connector is ideal for indoor applications. The temperature range of –49°F to 194°F (–45° to 90°C) ensures versatility across various environments. With dimensions of 6.18" in length, 1.77" in width, and 3.17" in height, the Morris 97308 is a compact yet powerful tool for building professionals seeking dependable electrical connections.

With our Clear In-Line Insulated Connector, you'll see your termination is right every time

• Clear Insulation allows Visual Confirmation that conductor is properly inserted
• Indoor Use Only
• Easy Re-Entry for Changes, Inspection or Troubleshooting
• In-Line 6061-T6 Aluminum Connector - CU9AL Dual Rated for use with Copper and/or Aluminum wire
• Insulated aluminum connector eliminates the need for time consuming manual taping, reducing installation time
• PVC insulation reduces the likelihood & cost of power outages caused by improper or inconsistent insulated connections done manually in the field
• Rated for use with 194°F(90°C) Cables
• One Wire Per Terminal
• Removable Plugs marked with wire size provide easy access for installation.
• Single Piece Clear Molded Insulation with Rugged High-Dielectric Plastisol Dipped Coating is chemical and abrasion resistant
• Pre-filled with Oxide Inhibitor
• 600 Volt
• Wire entry from either end of clear connector
• Dimension Measurements = Inches
• Temperature range of –49°F to 194°F (–45° to 90°C)
• ANSI C119.4 & cULus 486b Listed
