Morris 97450 Clear Multi Conductor Insulated Connector ensures a reliable termination every time. Designed with clear insulation, this connector allows for visual confirmation that conductors are properly inserted, minimizing the risk of errors during installation. The multi-port 6061-T6 aluminum construction is dual-rated for use with both copper and aluminum wire, making it a versatile choice for various applications. Each connector features a rugged, single-piece molded insulation coated in high-dielectric plastisol, which is resistant to chemicals and abrasion. Pre-filled with an oxide inhibitor, it provides additional protection against corrosion. The design allows for easy re-entry, making changes, inspections, or troubleshooting straightforward. Removable plugs marked with wire sizes facilitate convenient installation, while the ability to connect wires from either side enhances flexibility. With a temperature range of –49°F to 194°F (–45° to 90°C) and a 600-volt rating, this connector is ideal for indoor use. The PVC insulation significantly reduces the likelihood of power outages caused by improper manual connections, ensuring a more reliable electrical system. Compact in size with dimensions of 1.45" height, 1.50" length, and 1.10" width, the Morris 97450 is an essential addition to any professional toolkit.
With our Clear Multi Conductor Insulated Connector, you'll see your termination is right every time
Al9cu Dual Rating: AL9CU Dual Rated
Color: Clear
Connector Type: Single Entry
Country of Origin: India
Description: Clear Insulated Multi-Cable Connector - Single Entry 3 Port 4-14
Height: 1.45"
Insulation Type: Rubber
Length: 1.50"
Material: 6061-T6 Aluminum
Maximum Voltage: 600
Mfg Standard: UL 486B
No. of Ports: 3
Temperature Rating: -49oF to 194oF (-45o to 90oC)
Type: Clear Insulated Multi-Cable Connector - Single Side Entry
Ul Listing: cULus
Upc: 601986974509
Warning: Cancer and Reproductive Harm
Width: 1.10"
Wire Range: 4-14
Wire Size: 4-14
