Morris 97451 Clear Multi Conductor Insulated Connector offers a reliable solution for electrical terminations, ensuring that your connections are accurate every time. The clear insulation provides visual confirmation that conductors are properly inserted, allowing for quick checks during installation. Constructed from durable 6061-T6 aluminum, this multi-port connector is dual rated for use with both copper and aluminum wire, making it versatile for various applications. The rugged high-dielectric plastisol dipping enhances the connector's resistance to chemicals and abrasion, while the pre-filled oxide inhibitor helps maintain connection integrity over time. Designed for ease of use, it features removable plugs marked with wire sizes for straightforward installation and easy re-entry for modifications or inspections. Operating within a temperature range of –49°F to 194°F (–45° to 90°C), this connector is rated for 600 volts and is suitable for indoor use only. The Morris 97451 accommodates wire sizes from 4 to 14 and eliminates the need for time-consuming manual taping, significantly reducing installation time. With ANSI C119.4 and cULus 486b listings, this connector stands out for its safety and reliability, making it a practical choice for professionals in the field.
With our Clear Multi Conductor Insulated Connector, you'll see your termination is right every time
Al9cu Dual Rating: AL9CU Dual Rated
Color: Clear
Connector Type: Single Entry
Country of Origin: India
Description: Clear Insulated Multi-Cable Connector - Single Entry 4 Port 4-14
Height: 1.45"
Insulation Type: Rubber
Length: 1.92"
Material: 6061-T6 Aluminum
Maximum Voltage: 600
Mfg Standard: UL 486B
No. of Ports: 4
Temperature Rating: -49oF to 194oF (-45o to 90oC)
Type: Clear Insulated Multi-Cable Connector - Single Side Entry
Ul Listing: cULus
Upc: 601986974516
Warning: Cancer and Reproductive Harm
Width: 1.10"
Wire Range: 4-14
Wire Size: 4-14
