Morris 97482 Clear Multi Conductor Insulated Connector for Accurate Termination

Morris 97482 Clear Multi Conductor Insulated Connector ensures precise terminations with every use. Designed with a clear insulation, this connector allows for visual confirmation that conductors are correctly inserted, promoting accuracy in installations. The robust multi-port connector is constructed from 6061-T6 aluminum and is dual-rated for compatibility with both copper and aluminum wire, accommodating a wire range of 3/0-6. The single-piece clear molded insulation, coupled with a rugged high-dielectric plastisol dipped coating, offers exceptional chemical and abrasion resistance. Additionally, the connector is pre-filled with an oxide inhibitor, enhancing its longevity and performance. Easy re-entry features facilitate changes, inspections, or troubleshooting, while removable plugs marked with wire sizes provide straightforward access for installation. Designed for indoor use only, the Morris 97482 operates within a temperature range of –49°F to 194°F (–45° to 90°C) and is rated for up to 600 volts. The insulated aluminum construction eliminates the need for time-consuming manual taping, significantly reducing installation time and minimizing the risks associated with improper connections. ANSI C119.4 and cULus 486b listed, the Morris 97482 connector is a reliable choice for building professionals and knowledgeable homeowners alike.

With our Clear Multi Conductor Insulated Connector, you'll see your termination is right every time

• Wire Entry from Either Side of Clear Insulated Connector
• Clear Insulation allows Visual Confirmation that conductor is properly inserted
• Indoor Use Only
• Easy Re-Entry for Changes, Inspection or Troubleshooting
• PVC insulation reduces the likelihood & cost of power outages caused by improper or inconsistent insulated connections done manually in the field
• Rated for use with 194°F(90°C) Cables
• Insulated Aluminum Connector eliminates the need for time consuming manual taping, reducing installation time
• One Wire Per Terminal
• Removable Plugs marked with wire size provide easy access for installation.
• Single Piece Clear Molded Insulation with Rugged High-Dielectric Plastisol Dipped Coating is chemical and abrasion resistant
• Multi-Port 6061-T6 Aluminum Connector - CU9AL Dual Rated for use with Copper and/or Aluminum wire
• Pre-filled with Oxide Inhibitor
• 600 Volt
• Dimension Measurements = Inches
• Temperature range of –49°F to 194°F (–45° to 90°C)
• ANSI C119.4 & cULus 486b Listed
