Morris 97489 Clear Multi Conductor Insulated Connector offers a reliable solution for your electrical connections. Featuring clear insulation, this connector allows for visual confirmation that the conductor is properly inserted, ensuring accuracy with every installation. It is crafted from multi-port 6061-T6 aluminum, making it dual-rated for use with both copper and aluminum wire. The single-piece clear molded insulation is coated with a rugged high-dielectric plastisol, providing chemical and abrasion resistance. Pre-filled with oxide inhibitor, this connector guarantees longevity and performance. Designed for easy re-entry, it simplifies changes, inspections, or troubleshooting, while the removable plugs marked with wire size enhance accessibility during installation. With a temperature range of –49°F to 194°F (–45° to 90°C), the Morris 97489 is rated for indoor use only and can handle up to 600 volts. Its innovative design eliminates the need for time-consuming manual taping, significantly reducing installation time. The connector accommodates one wire per terminal and supports wire ranges from 250 to 6. Certified with ANSI C119.4 and cULus 486b listings, it’s a dependable choice for ensuring consistent, insulated connections and minimizing the risk of power outages in your projects.
With our Clear Multi Conductor Insulated Connector, you'll see your termination is right every time
Al9cu Dual Rating: AL9CU Dual Rated
Color: Clear
Connector Type: Single Entry
Country of Origin: India
Description: Clear Insulated Multi-Cable Connector - Single Entry 4 Port 250-6
Height: 2.37"
Insulation Type: Rubber
Length: 3.29"
Material: 6061-T6 Aluminum
Maximum Voltage: 600
Mfg Standard: UL 486B
No. of Ports: 4
Temperature Rating: -49oF to 194oF (-45o to 90oC)
Type: Clear Insulated Multi-Cable Connector - Single Side Entry
Ul Listing: cULus
Upc: 601986974899
Warning: Cancer and Reproductive Harm
Width: 2.48"
Wire Range: 250-6
Wire Size: 250-6
