NGP 137NA 96" Anodized Aluminum Neoprene Bulb Perimeter Seal delivers superior performance and durability for commercial restroom applications. Crafted from high-quality Aluminum Alloy 6063 with a T5 temper, this perimeter seal is designed to withstand the rigors of everyday use while maintaining its integrity. The synthetic EPDM rubber, set in a polypropylene thermoplastic matrix, offers excellent abrasion resistance, tensile strength, and memory, ensuring a long-lasting seal. This product is engineered to meet stringent safety standards, being flame-resistant and compliant with BHMA ANSI/BHMA A156.22 performance tests for heat and cold. It performs exceptionally well in a wide temperature range of -81°F to 275°F, making it suitable for various environments. Additionally, the seal boasts good resistance to ozone, sunlight, and aging, ensuring it remains effective over time. Installation is straightforward, thanks to the included #6 x 3/4" stainless steel sheet metal screws and slotted screw holes for easy adjustment. With its sleek black finish and anodized aluminum construction, the NGP 137NA not only provides functionality but also complements modern restroom aesthetics. Ideal for building professionals seeking reliable restroom partition hardware, this perimeter seal enhances both performance and longevity in any facility.
Attributes
Ship via: No UPS - Common Carrier Only
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Color is Black
Commercial Residential: Commercial
Fasteners: #6 x 3/4" Stainless Steel Sheet Metal Screws Furnished
Finish: Anodized Aluminum
Finish Description: Milled Aluminum
Finish Family: Matte Silver
Fire Rated: Flame-Resistant
Fire Rating: 3 Hours
Flange Material: Anodized Aluminum
Hardware: #6 x 3/4" Stainless Steel Sheet Metal Screws
Insert Color: Black
Insert Material: Neoprene
Installation: Commercial
Length: 96.0"
Material: Aluminum Alloy 6063, T5 Temper
Moisture Resistant: YES
Pack Qty: 1
Resistance: Good Resistance to Ozone, Sunlight and Aging
Series: NGP Gasketing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: ACOUSTICAL TESTED to ASTM E90 Standard Test Method for Laboratory Measurement of Airborne Sound Transmission Loss of Building Partitions and Elements, and ASTM E2235 Standard Test Method for Determination of Decay Rates for use in Sound Insulation Test Methods. Refer to information on pages G8 thru G10 of our Gasketing catalog for test result data.
Standard-4: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-5: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Standards: ANSI/UL10C (Catgory J), CAN4/ULC-S104, ANSI/UL10B, ANSI/UL1784, ANSI/BHMA A156.22
Temperature Range: Temperature Range -81°F to 275°F
Type: Perimeter Door Seal
Ul Listing: UL10C
Unit of Measure: Each
