NGP 13TA 60" Anodized Aluminum Thermoplastic Door Shoe is designed to offer robust protection and enhanced functionality for commercial restroom applications. Constructed from durable Aluminum Alloy 6063 with a T5 temper, this door shoe features a thermoplastic polymer seal complemented by a rigid base and soft vinyl fins, ensuring a secure fit and effective barrier against the elements. This product excels in moisture resistance, flame resistance, and performs reliably within a temperature range of 0°F to 140°F. The dark brown thermoplastic insert seamlessly integrates with various design aesthetics while providing long-lasting performance. Equipped with #6 x 3/4" stainless steel sheet metal screws, installation is straightforward and efficient. For added peace of mind, the NGP 13TA is certified by UL to meet stringent fire safety standards, making it suitable for hollow metal fire doors rated up to 3 hours and wood fire doors rated up to 90 minutes. Its design minimizes oxidative degradation, ensuring longevity even under exposure to cold, heat, and UV radiation. With a maximum length of 48 inches, this door shoe is an economical choice for enhancing safety and functionality in high-traffic restroom environments.
60" Anodized Aluminum Thermoplastic Door Shoe
Color: Thermoplastic Insert is Dark Brown
Fasteners: #6 x 3/4" Stainless Steel Sheet Metal Screws Furnished
Finish: Anodized Aluminum
Fire Rated: Flame resistant
Length: 60.0"
Material: Thermoplastic Polymer Seal with Rigid Base and Soft Vinyl Fins
Maximum Length: 48" Maximum Length
Moisture Resistant: YES
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Temperature Range: Temperature Range 0°F to 140°F
