NGP 157MA 60" Anodized Aluminum Magnetic Seal offers a robust solution for enhancing the functionality and efficiency of commercial restroom partitions. Constructed from durable aluminum alloy 6063 with a T5 temper, this magnetic seal is designed to withstand various environmental challenges. The thermoplastic polymer, Polyvinyl Chloride (PVC), is formulated with an environmentally friendly bio-based plasticizer, ensuring both sustainability and resilience. This seal is flame resistant, moisture resistant, and can operate within a temperature range of 0°F to 140°F, making it suitable for diverse applications. With a maximum length of 144", the NGP 157MA is versatile enough to accommodate different partition sizes. The magnetic strip, encased in brown vinyl, provides a secure closure while enhancing the aesthetic appeal. Installation is straightforward, thanks to the included #6 x 3/4" stainless steel SMS fasteners and slotted screw holes that allow for easy adjustment. Certified by UL for fire safety and air infiltration, this product complies with necessary regulations, ensuring peace of mind in commercial settings. Choose the NGP 157MA 60" Anodized Aluminum Magnetic Seal for a reliable and efficient partition enhancement that combines durability with eco-friendly design.
60" Anodized Aluminum Magnetic Seal
Color: Magnet encased in brown vinyl
Fasteners: #6 x 3/4" stainless steel SMS furnished
Finish: Anodized aluminum
Fire Rated: Flame resistant
Length: 60.0"
Material: Thermoplastic polymer: Polyvinyl Chloride (PVC) formulated with an environmentally friendly Bio-based plasticizer
Maximum Length: Maximum length 144"
Moisture Resistant: YES
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Temperature Range: Temperature range 0°F to 140°F
