NGP 203NA 48" Anodized Aluminum Neoprene Door Sweep is designed for durability and exceptional performance in commercial restroom environments. Constructed from high-quality Aluminum Alloy 6063 in T5 Temper, this door sweep combines strength with lightweight convenience. Its synthetic EPDM rubber embedded in a polypropylene thermoplastic matrix ensures outstanding abrasion resistance, tensile strength, and memory, making it a reliable choice for high-traffic areas. This door sweep is moisture-resistant and has been rigorously tested to perform effectively in a temperature range from -81°F to 275°F. It also boasts excellent resistance to ozone, sunlight, and aging, ensuring longevity in various conditions. The NGP 203NA is BHMA certified to ANSI/BHMA A156.22 standards, assuring compliance with rigorous performance tests for heat and cold. Installation is straightforward, thanks to slotted screw holes that allow for easy adjustment. The included #6 x 1" stainless steel SMS fasteners provide added security. With a sleek black finish, the anodized aluminum not only enhances the aesthetic appeal but also contributes to the overall longevity of the product. Whether you're updating existing partitions or installing new ones, this door sweep is a practical and effective solution for maintaining energy efficiency and comfort.
Attributes
Restriction message: Due to the fragile nature of this item, it can be easily damaged in shipping. The following charges apply to insure your items arrive in good condition. 1 to 12 Pieces: $19.50 13 to 24 Pieces: $39.50 25 to 36 Pieces: $58.50
Alternate Codes: 203NA 48IN, 203NA48IN
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Category: Door Accessories, Glass Aluminum Hardware, Thresholds & Seals
Color: Color is Black
Commercial Residential: Commercial
Fasteners: #6 x 1" Stainless Steel SMS Furnished
Finish: Anodized Aluminum
Finish Description: Satin Aluminum Clear Anodized
Finish Family: Matte Silver
Fire Rated: 3 Hours
Fire Rating: 3 Hours
Flange Material: Anodized Aluminum
Hardware: #6 x 3/4" Stainless Steel Sheet Metal Screws
Insert Color: Black
Insert Material: Neoprene
Installation: Commercial
Length: 48.0"
Material: Aluminum Alloy 6063, T5 Temper
Moisture Resistant: YES
Pack Qty: 1
Resistance: Good Resistance to Ozone, Sunlight and Aging
Restrictions: Fragile
Series: NGP Gasketing
Standard-0: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-1: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Standards: UL Classified UL10C Category H, ANSI/BHMA Certified A156.22
Subtype: Weatherstrip
Temperature Range: Temperature Range -81°F to 275°F
Type: Neoprene Sweep
Ul Listing: UL10C
Unit of Measure: Each
