NGP 411 36" Mill Aluminum Smooth Surface Saddle Threshold is engineered for durability and performance, making it an ideal choice for commercial restroom applications. Constructed from aluminum alloy 6063 with T5 temper, this threshold measures 3" wide and stands 1/4" tall, providing a smooth transition between spaces. Its mill finish not only enhances aesthetics but also ensures long-lasting wear. This threshold is particularly recommended for use with automatic door bottoms, ensuring an effective seal while maintaining accessibility. It adheres to ADA standards for barrier-free thresholds, meeting the requirements of the ADA Standard for Accessible Design and ICC/ANSI A117.1. Weighing just 0.50 lbs/ft, it is lightweight yet robust enough to handle daily use. Included with the threshold are #10 x 1-1/2" FH zinc plated wood screws, making installation straightforward and efficient. Additionally, the NGP 411 is certified by UL for fire door applications, compliant with NFPA standards, ensuring safety in critical environments. With a typical wall thickness of 0.125", this threshold provides a reliable solution for both function and compliance, making it a smart investment for any commercial restroom project.
36" Mill Aluminum Smooth Surface Saddle Threshold, 1/4" x 3"
Features
Alternate Codes: 411 36IN, 41136IN
Category: Door Accessories, Glass Aluminum Hardware, Thresholds & Seals
Dimensions: 3" wide x 1/4" tall
Fasteners: #10 x 1-1/2" FH zinc plated wood screws included
Finish: Mill finish
Finish Description: Milled Aluminum
Fire Rated: 3 Hours
Flange Material: Mill
Hardware: #10 x 1-1/2" FH Zinc Plated Wood Screws
Length: 36.0"
Material: Aluminum alloy 6063, T5 temper
Series: NGP Thresholds
Standard-0: ADA COMPLIANT. Barrier Free Thresholds meet the requirements of the ADA Standard for Accessible Design and ICC/ANSI A117.1 Accessible and Usable Buildings and Facilities.
Standard-1: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-3: ANSI/BHMA CERTIFIED. Certified thresholds comply with American National Standard for Thresholds ANSI/BHMA A156.21 1,000 lb. load test and are listed in the BHMA Certified Products Directory.
Standards: ADA, UL Classified UL10C, ANSI/BHMA Certified A156.21
Subtype: Threshold
Type: Saddle Threshold
Wall Thickness: Typical wall thickness .125"
Weight: Weight: .50 lbs./ft.
