NGP 440DKB 48" DKB-finish Aluminum Saddle Threshold is an essential component for creating accessible and durable entrances in commercial settings. Constructed from high-quality aluminum alloy 6063 with T5 temper, this threshold boasts an impressive fluted top design, enhancing both aesthetics and functionality. Measuring 10" wide and 1/4" tall, it meets ADA compliance standards, ensuring barrier-free access for all users. Certified by BHMA to ANSI/BHMA A156.21, this product has successfully passed a rigorous 1,000 lb. load test, confirming its strength and reliability. Weighing just 1.43 lbs. per foot, it’s lightweight yet robust, making installation straightforward. Each unit comes complete with #10 x 1-1/2" FH zinc-plated wood screws for easy setup. The dark bronze/black anodized finish not only provides a sleek look but also enhances corrosion resistance, ensuring longevity in high-traffic areas. Additionally, the NGP 440DKB threshold is certified by UL for fire door applications, complying with NFPA standards for safety. Ideal for both new constructions and renovations, it integrates seamlessly into various architectural designs while providing the durability needed for everyday use.
48" DKB-finish Aluminum Saddle Threshold, 1/4" x 10"
BHMA: BHMA Certified to ANSI/BHMA A156.21 1,000 Lb. Load Test
Dimensions: 10" wide x 1/4" tall
Fasteners: #10 x 1-1/2" FH zinc plated wood screws included
Finish: Dark bronze/black anodized finish
Length: 48.0"
Material: Aluminum alloy 6063, T5 temper
Standard-0: ADA COMPLIANT. Barrier Free Thresholds meet the requirements of the ADA Standard for Accessible Design and ICC/ANSI A117.1 Accessible and Usable Buildings and Facilities.
Standard-1: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-3: ANSI/BHMA CERTIFIED. Certified thresholds comply with American National Standard for Thresholds ANSI/BHMA A156.21 1,000 lb. load test and are listed in the BHMA Certified Products Directory.
Wall Thickness: Typical wall thickness .125"
Weight: Weight: 1.43 lbs./ft.
