NGP 92VA 36" Anodized Aluminum Extended Door Shoe with Vinyl Insert offers a durable solution for commercial restroom partitions. Constructed from high-quality aluminum alloy 6063 with T5 temper, this door shoe is designed to withstand the rigors of everyday use while maintaining its sleek appearance. The black vinyl insert is made from Polyvinyl Chloride (PVC) and incorporates an environmentally friendly Bio-based plasticizer, ensuring both safety and sustainability. This door shoe is flame resistant and moisture resistant, making it ideal for various environments, withstanding temperatures ranging from 0°F to 140°F. The included #6 x 3/4" stainless steel SMS fasteners ensure a secure installation, while optional end caps can be purchased separately for a polished finish. The NGP 92VA also meets rigorous safety standards, being certified by UL for application on Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes. Its design effectively controls smoke and draft, providing peace of mind in commercial settings. With its combination of functionality, durability, and aesthetic appeal, this door shoe is an excellent choice for building professionals seeking reliable restroom partition hardware.
36" Anodized Aluminum Extended Door Shoe with Vinyl Insert
Color: Vinyl is black
Fasteners: #6 x 3/4" stainless steel SMS furnished
Finish: Anodized aluminum
Fire Rated: Flame resistant
Length: 36.0"
Material: Thermoplastic polymer: Polyvinyl Chloride (PVC) formulated with an environmentally friendly Bio-based plasticizer
Moisture Resistant: YES
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Temperature Range: Temperature range 0°F to 140°F
