NGP 96VA 48" Anodized Aluminum Vinyl Door Sweep is designed to deliver exceptional performance while maintaining durability in commercial restroom settings. Constructed from high-quality aluminum alloy 6063 with T5 temper, this door sweep is both flame and moisture resistant, ensuring longevity and reliability. The thermoplastic polymer, made from polyvinyl chloride (PVC) with an eco-friendly bio-based plasticizer, offers excellent resistance to oxidative degradation, minimizing wear from exposure to temperature variations and UV light. With a temperature range of 0°F to 140°F, the NGP 96VA is ideal for various environments. It features a sleek black vinyl component, enhancing aesthetic appeal while providing effective sealing against air infiltration and drafts. The door sweep is certified by UL to meet multiple standards, including smoke and draft control, making it suitable for hollow metal and wood fire doors rated up to three hours. Installation is straightforward with the provided #6 x 3/4" stainless steel SMS fasteners and slotted screw holes for adjustment, allowing for a precise fit. This economical solution not only enhances energy efficiency but also contributes to a comfortable restroom experience. Upgrade your commercial space with the reliability and performance of the NGP 96VA Vinyl Door Sweep.
48" Anodized Aluminum Vinyl Door Sweep
Color: Vinyl is black
Fasteners: #6 x 3/4" stainless steel SMS furnished
Finish: Anodized aluminum
Fire Rated: Flame resistant
Length: 48.0"
Material: Thermoplastic polymer: Polyvinyl Chloride (PVC) formulated with an environmentally friendly Bio-based plasticizer
Moisture Resistant: YES
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Temperature Range: Temperature range 0°F to 140°F
