NGP 99NDKB 72" DKB-finish Aluminum Extended Door Shoe with Neoprene Insert offers exceptional durability and performance for commercial restroom applications. Crafted from Aluminum Alloy 6063 with T5 Temper, this door shoe is built to withstand the rigors of everyday use. The synthetic EPDM rubber insert enhances its effectiveness, providing excellent abrasion resistance and tensile strength while maintaining memory for a snug fit. Designed for versatility, the NGP 99NDKB is flame-resistant and moisture-resistant, making it suitable for a wide range of environments. It performs well across a temperature range of -81°F to 275°F, ensuring reliability in various conditions. Additionally, it boasts good resistance to ozone, sunlight, and aging, making it a long-lasting choice for high-traffic areas. This door shoe is BHMA certified to ANSI/BHMA A156.22 performance tests for heat and cold, guaranteeing its quality and performance standards. Included with the product are #6 x 3/4" stainless steel SMS fasteners, ensuring a secure installation. The striking dark bronze finish adds an aesthetic appeal, while optional end caps are available separately for a complete look. Choose the NGP 99NDKB for superior quality and functionality in your restroom partition hardware solutions.
Attributes
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Color is Black
Fasteners: #6 x 3/4" Stainless Steel SMS Furnished
Finish: Dark Bronze Finish
Fire Rated: Flame-Resistant
Length: 72.0"
Material: Aluminum Alloy 6063, T5 Temper
Moisture Resistant: YES
Resistance: Good Resistance to Ozone, Sunlight and Aging
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 96" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: SMOKE & DRAFT CONTROL GASKETING. Certified by UL to ANSI/UL10C and ANSI/UL1784 Category ‘H’; complies with IBC and NFPA 105 for use on ‘S’ labeled Positive Pressure Hollow Metal fire doors rated up to 3 hours, and Wood fire doors rated up to 90 minutes.
Standard-4: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature Range -81°F to 275°F
