NGP B606A (SET) 48" Anodized Aluminum Surface Mounted Astragal delivers superior performance and durability for commercial restroom partitions. Constructed from high-quality aluminum alloy 6063 with T5 temper, this astragal is designed to withstand the rigors of daily use while maintaining its integrity. With its excellent abrasion resistance, flexibility, and memory, the NGP B606A ensures a reliable fit and function, even in challenging environments. The synthetic polymer, polyamide, adds moisture resistance, making it ideal for restroom applications. This product is also REACH and RoHS compliant, reflecting NGP's commitment to environmental standards. The B606A operates effectively within a temperature range of -70°F to 425°F and is BHMA certified to ANSI/BHMA A156.22 performance tests for heat and cold, ensuring long-lasting performance. Each set includes two pieces and comes with #6 x 3/4" stainless steel sheet metal screws, with slotted screw holes for easy adjustment. Designed for seamless integration, the anodized aluminum finish not only enhances aesthetics but also provides additional protection against wear and tear. Upgrade your restroom facilities with the NGP B606A astragal, combining functionality with industry-leading standards for safety and reliability.
48" Anodized Aluminum Surface Mounted Astragal
BHMA: BHMA Certified to ANSI/BHMA A156.22 Performance Tests for Heat and Cold
Color: Nylon is gray
Fasteners: #6 x 3/4" stainless steel sheet metal screws furnished
Finish: Anodized aluminum
Length: 48.0"
Material: Synthetic polymer: Polyamide
Moisture Resistant: YES
Resistance: Excellent abrasion resistance, flexibility and memory
Ro HS: REACH and RoHS compliant
Standard-0: CERTIFIED by UL to CAN/ULC-S104 and ANSI/UL10B, complies with NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-1: POSITIVE PRESSURE - CERTIFIED by UL to ANSI/UL10C, complies with IBC, NFPA 80 and NFPA 252 for application to Hollow Metal fire doors rated up to 3 Hrs., and Wood fire doors rated up to 90 minutes.
Standard-2: AIR INFILTRATION TESTED to ASTM E283, Standard Test Method for Determining Rate of Air Leakage Through Exterior Windows, Curtain Walls, and Doors.
Standard-3: ANSI/BHMA CERTIFIED. Certified Gasketing complies with American National Standard for Door Gasketing and Edge Sealing Systems ANSI/BHMA A156.22 and is listed in the BHMA Certified Products Directory.
Temperature Range: Temperature range -70°F to 425°F
