Prodatakey HVC High-Voltage Converter, 12VDC/2A, 18 Gauge Wire, UL FCC Certified

Prodatakey HVC High-Voltage Converter with Enclosure provides a reliable solution for powering cloud nodes or single I/O devices in areas with access to high voltage power. This converter efficiently transforms input voltages ranging from 90 to 264VAC into a stable 12VDC output at 2 amps, making it an ideal choice for eliminating the need for extensive wiring to controllers. Designed with user convenience in mind, the HVC boasts an impressive efficiency rating of over 82% at varying loads (25%, 50%, and 100%). Its protective features ensure safe operation, automatically recovering from over-current, over-temperature, short circuits, and over-voltage situations. The converter operates effectively within a temperature range of 0°C to +50°C and offers remarkable reliability with a lifespan exceeding 100,000 hours under normal conditions. The HVC is housed in a durable, lockable metal enclosure, measuring 5" x 5" x 2", suitable for indoor use. Weighing just 1.37 lbs, it combines portability with robust performance. With certifications including UL, FCC, and CE, you can trust the HVC to meet stringent electrical safety standards. Enhance your access control system's efficiency and reliability with the Prodatakey HVC High-Voltage Converter.

High-Voltage Converter with Enclosure, Converts Line Voltage to 12VDC/2 Amps, 18 Gauge 2 Conductor Wire, UL, FCC

Power up the cloud node or single io in areas where high voltage power is available. The hv converter accepts 90 - 264VAC and converts it to 12VDC at 2a. It’s perfect for interfacing with the nearest high voltage source and eliminating the need to run a power wire to controllers.

Specifications:

• Input:
• Voltage Range: 90~264Vac auto range
• Frequency: 47~63Hz
• Efficiency: The average efficiency at 25%, 50%, and 100% load ≥ 82%
• Input Current: 90~132Vac / 12V / 2A load ≥ 1A 180~264Vac / 12V / 2A load ≥ 0.5A
• Output: 12V 0A to 2A
• Protection: Auto recovery on over-current, over-temp, short, over-voltage
• Environmental:
• Temperature: 0o ~ +50o C 100% load, +60o C 80% load, +70o C 60% load
• Storage temp: -20 to 70 ̊
• Operating humidity: 10% - 90%
• Storage humidity: 10% - 95%
• Isolation: CE: In conformance with EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC
• Reliability: >100,000 hours@ 100% load and normal inputs (25 ̊C)
• Enclosure: Dimensions (W x H x D) 5" x 5" x 2". Metal lockable security can (indoor use only)
• Weight: HVC - 1.37 lbs (22 oz)
• Electrical Safety: UL/cUL, TUV, CB by Demko, CCC, CE, KC, BSMI refer to EN 60950-1

Features

• Frequency: 47~63Hz
• Efficiency: The average efficiency at 25%, 50%, and 100% load ≥ 82%
• Output: 12V 0A to 2A
• Storage humidity: 10% - 95%
• Input:
• Voltage Range: 90~264Vac auto range
• Storage temp: -20 to 70 ̊
• Weight: HVC - 1.37 lbs (22 oz)
• Reliability: >100,000 hours@ 100% load and normal inputs (25 ̊C)
• Input Current: 90~132Vac / 12V / 2A load ≥ 1A 180~264Vac / 12V / 2A load ≥ 0.5A
• Enclosure: Dimensions (W x H x D) 5" x 5" x 2". Metal lockable security can (indoor use only)
• Electrical Safety: UL/cUL, TUV, CB by Demko, CCC, CE, KC, BSMI refer to EN 60950-1
• Temperature: 0o ~ +50o C 100% load, +60o C 80% load, +70o C 60% load
• Operating humidity: 10% - 90%
• Environmental:
• Protection: Auto recovery on over-current, over-temp, short, over-voltage
• Isolation: CE: In conformance with EMC Directive 2004/108/EC and Low Voltage Directive 2006/95/EC
