Prodatakey RDRSR Stainless Steel Mullion Reader is engineered for high-performance access control in demanding environments. This push button reader features a rugged backlit keypad, making it easy to use in low-light conditions, and its weatherproof design ensures durability even in harsh weather. Crafted from durable zinc alloy, the RDRSR is built to withstand the rigors of daily use. Equipped with a 125 kHz frequency input, this reader offers a read range of up to 1.8 inches, providing flexibility in how users gain access-via proximity credentials, a PIN, or a combination of both for enhanced security. The device supports a 26- to 37-bit Wiegand protocol output and can operate over a cable distance of up to 500 feet using 22 AWG wire. Designed to perform in extreme temperatures from -31°F to +140°F and humidity levels of 0 to 95% (non-condensing), the RDRSR has an IP67 protection rating, ensuring reliable operation in various conditions. The compact dimensions of 1.96" x 3.74" x 0.78" and a lightweight design of 0.83 lbs make it easy to install. For optimal performance, it requires a power supply of 6-16V DC with a maximum amperage of 30mA.
Stainless Steel Mullion Reader
The push button reader equipped with a rugged backlit keypad, weatherproof design, and a durable zinc alloy casing, is built for applications where durability is key. The push button reader offers the ability to unlock doors with proximity credentials, pin, or the flexibility to configure two-layer security by requiring users to present a credential and enter a pin to gain access.
Specifications:
Features
Alternate Codes: RDRSR
Category: Access Control, Hardwired, Prox Readers & Keypads (Hardwired)
