Richelieu 189LINX800HWT LIN-X800 Lateral Opening SystemRichelieu 189LINX800HWT LIN-X800 Lateral Opening System offers an innovative solution for accessing wood cabinet doors in overlay applications, accommodating a weight capacity of up to 40 kg (88.2 lb). This versatile system is designed for various environments, including pantries, closets, laundry storage, and hidden rooms. Choose from two height options-2400 mm and 2980 mm-tailoring the system to meet your specific needs. Available in sleek white or black finishes, the LIN-X800 enhances both aesthetics and functionality. Its adaptability extends to left- and right-hand mounting, ensuring seamless integration into any space. Engineered for smooth operation, the LIN-X800 features dampers for soft-closing capabilities and a vertical connecting rod that enhances stability. Adjustability in four different ways allows for precise installation, ensuring a perfect fit for door heights ranging from 63 to 117 inches and thicknesses between 15/16 to 1 9/16 inches. Designed for a single door with widths from 29 1/2 to 33 1/2 inches, this system combines simplicity with flexibility, making it the ideal choice for discerning builders and homeowners alike. For optimal accuracy during installation, be sure to use metric dimensions.
LIN-X800 Lateral Opening System
The LIN-X800 Lateral opening door system for one wood cabinet door for overlay applications for weight capacity 40 kg each.
Features:
* Select from two types of set for different door heights 2400 mm and 2980 mm
* Two choices of finishes white and black
* Can be mounted for left- and right-hand applications
* 4 way adjustable
* Smooth movement with dampers for smooth soft-closing
* Vertical connecting rod for superior stability
* Simple and Flexible
The LIN-X800 lateral opening door system is an ideal solution for Pantry, Closet, Laundry Storage and Hidden Rooms.
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Closet and Walk-In Closet, Pantry
Brand: LIN-X
Brand Model: Sugatsune/Lamp
Detailed Door Movement: Lateral Swing
Door Height: 1 600 to 2 980 mm
Door Material: Wood
Door Movement: Lateral
Door Position: Full Overlay
Door Thickness: 15/16 to 1 9/16 in*
Door Width: 29 1/2 to 33 1/2 in*
Finish: White
Load Capacity: 88.2 lb*
Number of Doors: 1
Opening: Lateral swing
Product #: 189LINX800HWT
Product type: Hinge
Product №: 189LINX800HWT
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Weight Capacity per Door: 88.2 lb*
