Richelieu 246015170 The Classic Barn Door Set offers a sophisticated solution for your sliding door needs, featuring a robust wall mount system designed specifically for a single wooden door. Crafted with a visible stainless steel flat bar, this top mount trolley can support doors weighing up to 80 kg (176 lb), making it ideal for both residential closets and walk-in spaces. The Classic Barn Door Set is available in three standard flat bar upper track options, complete with wall mounts and fastener lag bolts, ensuring a secure fit for wood wall constructions. Each track comes pre-drilled, allowing for easy connections to join tracks and optional soft-close mechanisms, sold separately. With a minimum door width requirement of 36 inches when using a soft-close feature and accommodating door thicknesses between 1 3/8 to 1 3/4 inches, this set is adaptable for various applications. The stylish rustic design enhances any space while providing practical functionality. Additionally, the set includes two stoppers and features a ball bearing roller type for smooth operation. The overall length can be adjusted between 78 3/4 to 118 inches, making it a versatile choice for your sliding door projects. Upgrade your interiors with the reliability and aesthetic appeal of the Richelieu Classic Barn Door Set.
The Classic Barn Door is a wall mount sliding door system for 1 wood door with visible stainless steel flat bar steel top mount trolley for doors weighing up to 80 kg (176 lb). Select from 3 choices of standard flat bar upper track sets with wall mounts and fastener lag bolts for wood wall construction. Each track is pre-drilled for connectors to join tracks and soft-close mechanisms (sold separately). For residential applications.
IMPORTANT: The minimum door width is 36 in (914 mm) when using a soft-close mechanism, and the maximum door weight is 176 lb (80 kg).
Attributes
Ship via: No UPS - Common Carrier Only
Application: Closet and Walk-In Closet, Standard Access Door, Barn Door
Brand: Onward
Detailed Door Movement: Barn door
Door Height: 3 050 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Projection: 64 mm
Door Thickness: 1 3/8 to 1 3/4 in
Door Width: 24 to 60 in
Finish: Stainless Steel (170)
Function: Sliding Door
Groove Depth: 20 mm
Groove Needed for Guiding System: Yes
Groove Width at the Bottom of Door: 7 mm
Height Clearance: 124 mm
Length - Overall Dimensions: 78 3/4 to 118 in*
Load Capacity: 33.1 to 176 lb*
Manufacturing Material: Stainless Steel
Material: Stainless Steel
Number of Doors: 1
Overall Length: 2 000 to 3 000 mm
Packaging Format: Box
Product #: 246015170
Product number: 246015170
Product type: Hardware Set
Product №: 246015170
Roller Position: Upper
Roller Type: Ball Bearing
Running Track Fixing: Surface Mount
Screw/ Nail Included: Yes
Set Screws Included: Yes
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Stopper: Two
Style: Rustic
Track Finish: Stainless Steel
Track Length: 2 to 3 m
Track Material: Stainless Steel
Track Mounting: Wall Mount
Track Type: Flat Bar
Track type: Flat Bar
Unit: Box
Unit 1: carton - 5
Unit 2: carton - 5
Weight Capacity per Door: 15 to 80 kg
