Images may not represent actual product and finish

Richelieu 355060185 K12 Arms for Upward Opening

Your Price: $68.88

Retail Price:$91.83

Your Savings:$22.95(25%)

Richelieu K12 Arms for Upward Opening

Part Number : RIC_355060185

Availability: 15176151 In Stock

Quantity

Description

Richelieu 355060185 K12 Arms for Upward Opening

Automatic and adjustable opening The K12 pneumatic suspension arm is a completely new way to open flap doors. It is specially designed for standard automatic drilling processes. The arm can be installed directly on solid doors or wider aluminum door frames.

Advantages and benefits

- Available in three lengths: 164 mm (6-7/16"), 244 mm (9-5/8") and 355 mm (14"), adapted for small, medium and large doors.
- For doors with an aluminum frame, a special adapter (#100013180) is sold separately.
- Enables a smooth and continuous movement of the door until it is fully opened.
- A rotating ring is integrated in the arm to allow an adjustment of the opening angle. Ideal for when several doors are aligned.
- The installation does not require additional screws, saving time and producing a more aesthetically pleasing look.
- All parts are made of a nickel-zinc alloy, steel and plastic.
- Minimalist design: 13 mm (33/64") diameter cylinder.
- Exclusive to Richelieu.

Important information

Please refer to the technical documents for additional information.

** Recommended drilling diameter for side panel: 9/16 in (15 mm) **

Application

For upward- or downward-opening doors

Included products

Two mounting options:
- Screw-on
- With dowel

Attributes

Brand: Italiana Ferramenta

Force: 6.12 kg

Force ( N): 60 Newton

Length: 355 mm

Opening Style: Upward opening

Opening Type: Lift-up Door

Opening Types: Lift-Up Opening

Opening Types NEW: Lift-Up Opening

Product #: 355060185

Product number: 355060185

Product №: 355060185

Type of Opening: Lift-Up Opening

Unit: Bag

Unit 1: case - 25

Unit 2: case - 25
