Richelieu 8910659L2005110 Bottom Track for Bridge 500/600Richelieu 8910659L2005110 Bottom Track for Bridge 500 and Bridge 600 is designed for seamless functionality in bypassing door systems. This robust track series supports single, double, and triple door configurations, making it an ideal choice for various applications. Available in two elegant finishes-satin aluminum and anodized satin black-this track enhances both aesthetics and durability. Choose between recess or surface mounting options to suit your installation needs. With lengths of 2 m (78 5/8 in) and 3 m (118 in), it accommodates a wide range of door sizes. Crafted from high-quality aluminum, the track is engineered to support a load capacity of up to 132 lb, ensuring reliable performance for both aluminum/metal frame and wooden doors. The design features lower roller positions for smooth straight sliding movements, enhancing the overall user experience. This product comes with a surface mount fixing method, and while it is not pre-drilled, it provides versatility for custom installations. Whether you're a professional builder or a knowledgeable homeowner, the Richelieu Bottom Track is a reliable solution for your sliding door needs, combining functionality with a sleek design.
Bottom Track for Bridge 500 and Bridge 600
The Track series for Bridge 500 and Bridge 600 bottom running system offers options for single, double, and triple bypassing doors.
Features:
* Select from recess or surface mount
* Available in 2 finishes, silver-like color and anodized satin black
* 2 m (78 5/8 in) and 3 m (118 in) options
Attributes
Compatible with: Bridge 600, Bridge 500
Detailed Door Movement: Bypassing
Door Installation: Bottom Running
Door Material: Aluminum/Metal Frame, Wood
Door Movement: Straight Sliding
Finish: Anodized Aluminum
Length - Overall Dimensions: 78 3/4 in*
Load Capacity: 132 lb*
Manufacturing Material: Aluminum
Overall Length: 2 000 mm
Packaging format: Length of 2 linear meter
Pre-drilled: No
Product #: 8910659L2005110
Product Type: Double Track
Product number: 8910659L2005110
Product type: Double Track
Product №: 8910659L2005110
Roller Position: Lower
Running Track Fixing: Surface Mount
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Finish: Satin Aluminum
Track Length: 2 000 mm
Track Material: Anodized Aluminum
Track Mounting: Surface
Track Type: Running
Track type: Running
Unit: Length of 2 linear meter
Weight Capacity per Door: 132 lb*
