Richelieu 8912683CHBRZ EVO Hardware SetRichelieu 8912683CHBRZ EVO Hardware Sets offer a versatile solution for both wood and glass doors, accommodating weights of up to 176 lb (80 kg) across three different capacity categories. Designed for wood doors with thicknesses ranging from 3/4 in (19 mm) to 1 3/8 in (36 mm) and glass doors from 5/16 in (8 mm) to 1/2 in (13 mm), these hardware sets can be adapted to various project requirements. Available in four sophisticated finishes-black, chrome, champagne, and titanium-this hardware brings both style and functionality to residential and commercial spaces. The inclusion of two adjustable soft-close mechanisms ensures a smooth and quiet operation, enhancing user experience. With a straightforward installation process, the EVO sets are perfect for closets, pantries, and access doors in washrooms, bedrooms, and offices. This top-hung system supports a maximum door height of 8 ft 6 in, with a projection of 3 5/32 in, and is engineered for single sliding movement. Constructed from durable aluminum and featuring ball-bearing rollers, the EVO Hardware Sets promise long-lasting performance and reliability. Elevate your interior design with Richelieu's exceptional hardware solutions that combine aesthetics with practicality.
EVO Hardware Sets
The EVO barn door style hardware sets for wood and glass doors for three different weight capacity categories: 88 lb (40 kg), 132 lb (60 kg), and 176 lb (80 kg).
Features:
- For wood doors 3/4 in (19 mm) to 1 3/8 in (36 mm) thick
- For glass doors 5/16 in (8 mm) to 1/2 in (13 mm) thick
- Available in four finishes: black, chrome, champagne, and titanium
- Includes two soft-close mechanisms, can be adjusted to different positions
- Smooth operating
- Simple, flexible, and low-cost installation
Ideal solution for residential and commercial applications for thin and thick doors, closets and pantries, and access doors for washrooms, bedrooms, and offices.
Attributes
Ship via: No UPS - Common Carrier Only
Detailed Door Movement: Single sliding, Barn door
Door Height: Max. 2 600 mm
Door Installation: Top Hung
Door Material: Wood (19 mm - 36 mm), Glass (8 mm - 10 mm)
Door Movement: Straight Sliding
Door Projection: 80 mm
Door Thickness: 8 to 36 mm
Door Width: 700 to 1 219 mm
Finish: Champagne
Height Clearance: 191 mm
Load Capacity: 33.1 to 88.2 lb*
Manufacturing Material: Aluminum
Material: Aluminum
Number of Doors: 1
Packaging Format: Box
Product #: 8912683CHBRZ
Product number: 8912683CHBRZ
Product type: Hardware Set
Product №: 8912683CHBRZ
Roller Position: Upper
Roller Type: Ball Bearing
Running Track Fixing: Bracket
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: Yes
Track Mounting: Wall Mount
Unit: Set
Weight Capacity per Door: 15 to 40 kg
