Richelieu 891268790 EVO Hardware SetRichelieu 891268790 EVO Hardware Sets offer an exceptional solution for both residential and commercial applications, accommodating wood and glass doors with varying weight capacities of 88 lb (40 kg), 132 lb (60 kg), and 176 lb (80 kg). Designed for wood doors ranging from 3/4 in (19 mm) to 1 3/8 in (36 mm) thick, and glass doors from 5/16 in (8 mm) to 1/2 in (13 mm), these hardware sets are versatile and easy to install. Available in four elegant finishes-black, chrome, champagne, and titanium-Richelieu's EVO hardware not only meets aesthetic demands but also features two adjustable soft-close mechanisms for smooth and silent operation. The top-hung design ensures seamless sliding for doors with a maximum height of 8 ft 6 in, while its low-cost installation makes it a practical choice for closets, pantries, and access doors in washrooms, bedrooms, and offices. Constructed from durable aluminum, these sets include ball bearing rollers for enhanced performance and longevity. With a straight sliding movement and a door projection of 3 5/32 in, the EVO hardware provides both functionality and style, making it an ideal choice for any project requiring efficient and attractive door solutions.
EVO Hardware Sets
The EVO barn door style hardware sets for wood and glass doors for three different weight capacity categories: 88 lb (40 kg), 132 lb (60 kg), and 176 lb (80 kg).
Features:
- For wood doors 3/4 in (19 mm) to 1 3/8 in (36 mm) thick
- For glass doors 5/16 in (8 mm) to 1/2 in (13 mm) thick
- Available in four finishes: black, chrome, champagne, and titanium
- Includes two soft-close mechanisms, can be adjusted to different positions
- Smooth operating
- Simple, flexible, and low-cost installation
Ideal solution for residential and commercial applications for thin and thick doors, closets and pantries, and access doors for washrooms, bedrooms, and offices.
Attributes
Ship via: No UPS - Common Carrier Only
Detailed Door Movement: Single sliding, Barn door
Door Height: Max. 2 600 mm
Door Installation: Top Hung
Door Material: Wood (19 mm - 36 mm), Glass (8 mm - 10 mm)
Door Movement: Straight Sliding
Door Projection: 80 mm
Door Thickness: 8 to 36 mm
Door Width: 700 to 1 219 mm
Finish: Black (90)
Height Clearance: 191 mm
Load Capacity: 33.1 to 88.2 lb*
Manufacturing Material: Aluminum
Material: Aluminum
Number of Doors: 1
Packaging Format: Box
Product #: 891268790
Product number: 891268790
Product type: Hardware Set
Product №: 891268790
Roller Position: Upper
Roller Type: Ball Bearing
Running Track Fixing: Bracket
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: Yes
Track Mounting: Wall Mount
Unit: Set
Weight Capacity per Door: 15 to 40 kg
