Richelieu 8925371 HAWA JUNIOR Removable Track Series InstructionsRichelieu 8925371 HAWA JUNIOR Removable Track Series offers a robust solution for sliding pocket doors, accommodating weights of up to 264 lb (120 kg) each. This track system is compatible with various HAWA JUNIOR models, including 80/Z, 80/B, 100/Z, 100/B, 120/A, and 120/B, making it a versatile choice for different applications. Designed for clip-on cover panels, the HAWA JUNIOR track allows for seamless integration into your space. Its removable feature simplifies installation, adapting easily through various construction stages. Available in two lengths-78 3/4 in (2 m) and 118 in (3 m)-this system offers flexibility to meet your project's specific needs. The track is constructed from durable aluminum, ensuring longevity while maintaining a sleek profile with an overall height of 2 1/16 in. Ideal for single sliding movements, it supports door thicknesses ranging from 1 3/8 in to 1 9/16 in and widths between 23 7/8 in and 49 1/4 in. For enhanced functionality, optional soft-close mechanisms can be purchased separately. When considering installation, utilize metric dimensions for the utmost precision. The HAWA JUNIOR Removable Track Series is the perfect choice for those seeking a reliable, efficient sliding door solution.
HAWA JUNIOR Removable Track Series
The HAWA JUNIOR Removable Track Series is designed for sliding pocket doors weighing up to 264 lb (120 kg) each.
Features:
- For sliding systems HAWA JUNIOR 80/Z, 80/B mod., 100/Z, 100/B, 120/A, and 120/B
- Designed for clip-on cover panels
- Can be easily removed for various stages of installation during construction
- Available in 78 3/4 in (2 m) and 118 in (3 m) lengths
- Soft-close mechanisms available (sold separately)
- Simple and flexible installation
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Pocket Door
Detailed Door Movement: Single sliding
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 35 to 40 mm
Door Width: 608 to 1 250 mm
Height: 52 mm
Length: 2 535 mm
Length - Overall Dimensions: 98 3/8 in*
Load Capacity: 176 to 220 lb*
Manufacturing Material: Aluminum
Material: Aluminum
Overall Height: 2 1/16 in*
Overall Length: 2 500 mm
Product #: 8925371
Product number: 8925371
Product type: Running and Guiding Tracks
Product №: 8925371
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Mounting: Recessed
Unit: Length
Weight Capacity per Door: 80 to 100 kg
Width: 40 mm
