Richelieu 8927663 HAWA JUNIOR 80/100 Track Series InstructionsRichelieu 8927663 HAWA JUNIOR 80/100 Track Series offers a robust solution for ceiling and wall-mounted sliding doors, accommodating weights up to 220 lb (100 kg) per door. This track series is compatible with the HAWA JUNIOR 80/Z, 80/B mod., 100/Z, and 100/B systems, making it versatile for various applications. Available in lengths of 78 3/4 in (2 m), 98 3/8 in (2.5 m), and 118 in (3 m), the tracks can be installed either on the surface or recessed for a sleek look. Wall mount tracks attach directly to the wall, and an optional spacer profile (sold separately) provides additional clearance when needed. The system supports single sliding door movements, ideal for standard access doors made of wood, with a maximum door thickness of 1 3/16 in. For added convenience, soft-close mechanisms are also available separately, enhancing user experience and safety. Easy to install, the HAWA JUNIOR 80/100 Track Series is designed with a manufacturing material of aluminum, ensuring durability and longevity. With an overall height of 1 9/16 in and a width of 3 5/32 in, this track system seamlessly integrates into any environment, providing both functionality and style.
HAWA JUNIOR 80/100 Track Series
The HAWA JUNIOR 80/100 Track Series is designed for ceiling and wall mount doors weighing up to 220 lb (100 kg) each.
Features:
- For sliding systems HAWA JUNIOR 80/Z, 80/B mod., 100/Z, and 100/B
- Surface and Recessed mount tracks
- Wall mount tracks are mounted directly to the wall; a spacer profile is available (sold separately) for greater clearance
- Available in 78 3/4 in (2 m), 98 3/8 in (2.5 m) and 118 in (3 m) lengths
- Soft-close mechanisms available (sold separately)
- Simple and flexible installation
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Standard Access Door
Brand: Hawa
Detailed Door Movement: Single sliding
Door Height: 13 ft 1 in*
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: Max. 1 3/16 in*
Door Width: 23 7/8 to 78 3/4 in*
Load Capacity: 220 lb*
Manufacturing Material: Aluminum
Overall Height: 1 9/16 in*
Overall Length: 13 ft 1 in*
Product #: 8927663
Product type: Running and Guiding Tracks
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Mounting: Recessed - Inside Ceiling
Width: 3 5/32 in*
