Richelieu 8927677 HAWA Junior 80/100 Track Series InstructionsRichelieu 8927677 HAWA JUNIOR 80/100 Track Series offers a reliable solution for sliding doors, accommodating weights of up to 220 lbs (100 kg). Crafted from durable aluminum, this track series is designed for both ceiling and wall mounting, making it adaptable to various installation needs. The HAWA JUNIOR is compatible with several sliding systems, including the HAWA JUNIOR 80/Z, 80/B, 100/Z, and 100/B models. It features both surface and recessed mount tracks, with wall-mounted options that can be directly affixed to the wall. For enhanced clearance, a spacer profile is available separately. Available lengths of 78 3/4 in (2 m), 98 3/8 in (2.5 m), and 118 in (3 m) cater to diverse project requirements. The product supports single sliding door movement, with a recommended maximum door thickness of 1 3/16 in and a width ranging from 23 7/8 to 39 3/8 in. For added convenience, soft-close mechanisms can be purchased separately, ensuring a smooth and quiet operation. With straightforward installation, the HAWA JUNIOR 80/100 Track Series is an excellent choice for professional builders and discerning homeowners seeking high-quality and functional hardware solutions.
HAWA JUNIOR 80/100 Track Series
The HAWA JUNIOR 80/100 Track Series is designed for ceiling and wall mount doors weighing up to 220 lb (100 kg) each.
Features:
- For sliding systems HAWA JUNIOR 80/Z, 80/B mod., 100/Z, and 100/B
- Surface and Recessed mount tracks
- Wall mount tracks are mounted directly to the wall; a spacer profile is available (sold separately) for greater clearance
- Available in 78 3/4 in (2 m), 98 3/8 in (2.5 m) and 118 in (3 m) lengths
- Soft-close mechanisms available (sold separately)
- Simple and flexible installation
IMPORTANT: Use metric dimensions for greater accuracy during installation.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Standard Access Door
Brand: Hawa
Detailed Door Movement: Single sliding
Door Height: 4 000 mm
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: Max. 30 mm
Door Width: 608 to 1 000 mm
Height: 40 mm
Length: 2 000 mm
Length - Overall Dimensions: 78 3/4 in*
Load Capacity: 220 lb*
Manufacturing Material: Aluminum
Material: Aluminum
Overall Height: 1 9/16 in*
Overall Length: 2 000 mm
Product #: 8927677
Product number: 8927677
Product type: Running and Guiding Tracks
Product №: 8927677
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Mounting: Ceiling Mount
Unit: Length
Weight Capacity per Panel: 100 kg
Width: 39 mm
