Richelieu 8930444 HAWA Junior Acoustics Seal KitsRichelieu 8930444 HAWA JUNIOR ACOUSTICS Seal Kits provide an innovative solution for enhancing the soundproofing and overall functionality of your sliding doors. Designed with automatic concealed retractable seals, these kits are seamlessly mounted at the top and bottom of the door, effectively closing the gap between the upper track and the floor. This installation not only blocks unwanted drafts, odors, and light but also delivers impressive sound attenuation, achieving up to 35 dB for wall mount sliding doors and up to 41 dB for pocket doors. Compatible with door thicknesses ranging from 44 to 50 mm (1-3/4 to 2 in), the seal kits are particularly suited for Hawa Junior 100 B and Porta 60/100 HMD & HMT series. With a selection of 8 different seal kits suitable for various door widths and sliding directions, customization is easy. The flexible seals conform to the floor shape, ensuring a tight fit, whether for pocket or wall mount applications. Installation requires precise metric measurements, including grooving the door for optimal performance. Ideal for both barn and pocket doors, Richelieu’s seal kits combine functionality with a sleek design, making them an essential addition to any modern space.
HAWA JUNIOR ACOUSTICS Seal Kits
HAWA JUNIOR ACOUSTICS Seal kits are automatic concealed retractable seals mounted horizontally at the top and bottom of the door. Seal kits provide sound attenuation and resist unwanted drafts, odors, and light. Seals are installed recessed the full width of the door, closing the gap between the upper track and the floor. Seals are triggered by the door stopper at the top and the floor guide at the bottom. The bottom seal includes an aluminum channel for its floor mounted guide.
Features:
- Sound attenuation effect up to 35 dB for wall mount sliding doors
- Sound attenuation effect up to 41 dB for pocket doors
- Suitable for door thickness of 44 to 50 mm (1-3/4 to 2 in)
- Compatible with the Hawa Junior 100 B and the Porta 60/100 HMD & HMT series
- Select from 8 different seal kits for different door widths and sliding directions (left or right)
- The seal is flexible and will conform to the shape of the floor
- Can used for pocket door and wall mount sliding applications
IMPORTANT: Use metric dimensions for greater accuracy during installation. The level of sound attenuation depends upon the use of vertical seals and the construction of the door and walls. Cut a groove 23 mm (29/32 in) x 30 mm (1-3/16 in) into the bottom of the door and 31 mm (1-7/32 in) x 30 mm (1-3/6 in) into the top of the door. Refer to the mounting instructions for more information.
Attributes
Ship via: No UPS - Common Carrier Only
Application: Barn Door, Pocket Door, Library
Brand: Hawa
Compatible with: Hawa Junior 100 B Acoustics
Detailed Door Movement: Right to left opening
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Thickness: 1 23/32 to 1 31/32 in*
Door Width: 48 to 49 1/4 in*
Height: 98 3/8 in*
Number of Doors: 1
Opening: Right to left opening
Overall Height: 98 3/8 in*
Product #: 8930444
Product type: Seal
Product №: 8930444
Roller Position: Upper
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Mounting: Wall Mount, Pocket Door
