Richelieu 89K4072DR290 BRIDGE 500 Sliding Door Kit for Aluminum FramesRichelieu 89K4072DR290 BRIDGE 500 KIT for Aluminum Framed Sliding Doors offers a robust solution for your sliding door needs, designed to support doors weighing up to 60 kg (132 lbs) each. This bottom-running sliding door system is suitable for various applications including closets, walk-in closets, wardrobes, pantries, and storage spaces. Available in two sophisticated finishes-Silver Anodized and Satin Black-the kit complements any modern interior. The Bridge 500 kit includes easy-to-assemble knock-down aluminum frame profiles with one horizontal divider, accommodating maximum door dimensions of 1000 x 2400 mm (39-3/8 x 94-1/2 in). Designed for versatility, it works seamlessly with 4 - 6 mm (3/16 - 1/4 in) thick glass or up to 10 mm (3/8") wood panels. The aluminum profiles can be cut to fit your specific door sizes. Choose from configurations for two doors with 2.0 m (78-3/4 in) double upper tracks or three doors with 3.0 m (118 in) triple tracks, all of which are surface-mounted. The kit comes complete with a pull handle, and three-door kits include a locator device for the middle door. Optional soft-close mechanisms are available for enhanced functionality. Ensure precision during installation by using metric dimensions for accuracy.
BRIDGE 500 KIT for Aluminum Framed Sliding Doors
The Bridge 500 bypassing aluminium frame door kit is a bottom-running sliding door system for doors weighing up to 60 kg (132 lbs) per door. Available in two finishes: Silver Anodized and Satin Black.
The kits include easy to assemble knock-down aluminium frame profiles with one horizontal divider. Maximum door size 1000 X 2400 mm (39-3/8 X 94-1/2 in).
The aluminium frame profiles are designed to work with 4 - 6 mm (3/16 - 1/4 in) thick glass with standard gasket or up to 10 mm (3/8") wood panels without a gasket. The aluminum frame profiles can be cut to suit the desired door sizes.
Select from Kits for two doors with 2.0 m (78-3/4 in) double upper tracks or three doors with 3.0 m (118 in) triple tracks. All tracks are surface mounted.
Includes pull handle.
Three-door kits include locator device for the middle door.
Optional soft-close with adjustable spring.
Important: Use metric dimensions for greater accuracy during installation.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Closet and Walk-In Closet, Wardrobe, Pantry, Storage
Brand: BRIDGE
Detailed Door Movement: Bypassing
Door Height: 2 400 mm
Door Installation: Bottom Running
Door Material: Aluminum/Metal Frame, Glass
Door Movement: Straight Sliding
Door Position: Inset/Inlay
Door Width: 39 3/8 in*
Finish: Black (90)
Length - Overall Dimensions: 78 3/4 in*
Load Capacity: 44.1 to 132 lb*
Number of Doors: 2
Overall Length: 2 000 mm
Packaging format: Length
Product #: 89K4072DR290
Product type: Complete Set
Product №: 89K4072DR290
Roller Position: Lower
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Track Mounting: Surface
Weight Capacity per Door: 44.1 to 132 lb*
