Richelieu BR05KT704 BR05 Door Stiffener and StraightenerRichelieu BR05KT704 BR05 Door Straightener/Stiffener is an essential solution for reinforcing tall wood doors, effectively preventing warping even in environments with fluctuating humidity. This aluminum profile features an adjustable threaded rod and is designed for doors up to 700 mm (27-1/2 in) wide, requiring just one profile for installation. For wider doors, two profiles are recommended, ensuring optimal support. Available in painted black or raw (unfinished) aluminum, the BR05 allows for customization to match your desired finish. The installation is straightforward, with adjustment typically at the top end of the door. You can choose to install the profile from top to bottom or set it in 90 mm (3-1/2 in) from both the top and bottom, allowing for flexibility in application. Designed for door heights ranging from 1600 mm to 2800 mm (63 in to 110 in) and accommodating door thicknesses between 23/32 to 1 3/16 in, this stiffener is compatible with various wood doors. However, it is important to note that it cannot straighten doors that are already warped or bent. For best results, use metric measurements during installation, ensuring a precise fit.
BR05 Door Straightener/Stiffener
The BR05 Door Straightener/Stiffener is an aluminum profile with adjustable threaded rod for reinforcing tall wood doors to resist warping. Mounted vertically in the middle of the door, only one profile is required for door widths of 700 mm (27-1/2 in) or less. For doors wider than 700 mm (27-1/2 in), use two profiles
.
Ideal for doors in environments with variable humidity levels and doors with a heavy finish on one face, such as laminated or painted doors.
Features:
- Select from painted black or raw (unfinished) aluminum so that you can finish to your own color
- Adjustment at one end, typically at the top end of the door
- The profile can be installed from the top to the bottom of the door or set in 90 mm (3-1/2 in) from the top and bottom of the door
- The profile can be cut to a minimum of 400 mm (15-3/4 in)
- Select from 3 sizes for door heights ranging from 1600 mm to 2800 mm (63 in to 110 in)
Important : We cannot guarantee that the hardware will straighten a door that is already warped or bent.
Use metric dimensions for the best accuracy during installation.
Attributes
Brand: CINETTO
Door Height: 63 to 78 3/4 in*
Door Material: Wood
Door Thickness: 23/32 to 1 3/16 in*
Door Width: 15 3/4 to 27 1/2 in*
Finish: Raw
Manufacturing Material: Steel, Aluminum
Number of Doors: 1
Overall Length: 52 5/8 to 68 3/8 in*
Product #: BR05KT704
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
