Richelieu 1890533390072 HAWA FRONTINO 20 H FS Coplanar Sliding System is a premium bottom-running sliding solution designed to accommodate two coplanar wooden doors, each weighing up to 44 lb (20 kg). Ideal for cabinet applications, this system enables smooth and ergonomic access to your furniture, allowing doors to slide gently across one another for an elegant and functional design. The HAWA FRONTINO system supports a cabinet width ranging from 55 1/8 to 63 inches, while accommodating door heights up to 39 3/8 inches. Crafted for full overlay door positioning, it requires a door thickness between 3/4 to 31/32 inches and a maximum door width of 31 3/8 inches, ensuring a perfect fit for various cabinetry styles. Included in this complete set is a sophisticated two-way soft-close mechanism, enhancing the user experience by providing a gentle, controlled closure. The adjustable features of the system allow for customized alignment, ensuring optimal performance and aesthetics. With its robust construction and high load capacity, the Richelieu HAWA FRONTINO 20 H FS ensures durability and reliability, making it an excellent choice for both building professionals and discerning homeowners looking to elevate their interior spaces.
HAWA FRONTINO 20 H FS Coplanar Sliding System
Adjustable: Yes
Application: Cabinet
Brand: Hawa
Brand Model: Hawa Fortino
Cabinet Width: 1 400 to 1 599 mm
Door Height: Max. 1 000 mm
Door Material: Wood
Door Movement: Coplanar
Door Position: Full Overlay
Door Thickness: 19 to 25 mm
Door Width: Max. 797 mm
Load Capacity: 44.1 lb*
Number of Doors: 2
Product #: 1890533390072
Product Type: Complete Set
Product number: 1890533390072
Product type: Complete Set
Product №: 1890533390072
Soft- Close Type: Two-Way Operation
Soft- Closing: Yes
Unit: Box
Weight Capacity per Door: 20 kg
