Richelieu H094C2JBP99 Series 200 Concealed Hinge - 94 offers an innovative solution for frameless cabinets requiring concealed hinges. This hinge features independent and compensation adjustment, ensuring precise alignment for a seamless finish. Designed with versatility in mind, it includes a safety stop device that accommodates both symmetrical and asymmetrical door configurations. Installation is a breeze with the snap-on mounting system, which allows for quick adjustments and easy integration with all Domi series quick-release mounting plates. The hinge supports a door opening angle of +94°, providing ample access while maintaining a sleek profile. With a load capacity of 10 lbs, it is ideal for thick doors, ensuring durability and reliability under constant use. Crafted with a nickel finish, the hinge not only delivers functionality but also adds an aesthetically pleasing touch to any cabinetry. The milling depth of 5/8 in and diameter of 1 3/8 in accommodates various installation needs with precision. The toolless fixing type simplifies the installation process even further. Richelieu's commitment to quality and design is evident in the H094C2JBP99 Series 200 Hinge, making it an essential choice for building professionals and discerning homeowners alike.
200 Series - Concealed Hinges 94 for Thick Door
Brand: Salice
Cabinet Type: Frameless
Closing Mechanism: Spring Closing
Crank: 21/32 in*
Diameter: 1 3/8 in*
Door Position: Inset
Door Thickness: 3/4 to 1 3/8 in*
Drilling Distance: 3 to 9 mm
Finish: Nickel
Fixing Type: Toolless
Hinge Opening Angle: +94°
Load Capacity: 10 lb
Mechanism: Spring Closing
Milling Depth: 15.5 mm
Milling Diameter: 35 mm
Overlay: 0.0781 in
Product #: H094C2JBP99
Product number: H094C2JBP99
Product №: H094C2JBP99
Production Time: Stock
Series: 200 Series
Unit 1: case - 300
Use Type: Thick Door
