Richelieu H120C2J9A99 Series 200 Concealed Hinge 120 offers a sophisticated solution for frameless cabinet applications requiring concealed hinges. This innovative hinge is designed with both independent and compensation adjustments, ensuring a perfect fit for your doors. Featuring a safety stop device, it accommodates both symmetrical and asymmetrical installations, enhancing versatility in various projects. The hinge boasts a snap-on mounting system, making installation straightforward and tool-free, which is especially beneficial for busy professionals. Compatible with all Domi series quick-release mounting plates, the H120C2J9A99 is adaptable to your specific needs. This hinge supports a full overlay door position with a drilling distance between 1/8 to 1/4 inches and offers a hinge opening angle of +120°, allowing for seamless access to cabinet interiors. Finished in a sleek nickel, this hinge not only performs well but also complements modern cabinetry aesthetics. With a load capacity of 10 lbs, it is robust enough for standard door applications. Additionally, the spring-closing mechanism ensures the door closes securely every time. The Richelieu H120C2J9A99 is a reliable choice for anyone looking to enhance cabinet functionality and design.
200 Series - Concealed Hinges 120
Brand: Salice
Cabinet Thickness: 5/8 to 1 1/32 in*
Cabinet Type: Frameless
Closing Mechanism: Spring Closing
Crank: 0 in*
Diameter: 1 3/8 in*
Door Position: Full Overlay
Drilling Distance: 3 to 6 mm
Finish: Nickel
Fixing Type: Toolless
Hinge Opening Angle: +120°
Load Capacity: 10 lb
Mechanism: Spring Closing
Milling Depth: 7/16 in*
Milling Diameter: 1 3/8 in*
Overlay: 0.75 in
Product #: H120C2J9A99
Product number: H120C2J9A99
Product №: H120C2J9A99
Production Time: Stock
Series: 200 Series
Unit 1: case - 300
Use Type: Standard Door
