Richelieu WEBKIT1216583 HAWA Variofold 80/H System for End Folding Partition Wall is designed to accommodate wood doors weighing up to 176 lb (80 kg) each, making it an ideal choice for both residential and commercial spaces. This system allows for seamless end folding of bifolding doors without the need for a bottom guide channel when using up to two folding panels, enhancing the aesthetic appeal of your interiors. For projects requiring greater stability, a lower guide channel is available for multiple folding door panels. The standard configuration supports door thicknesses ranging from 1 3/8 in (35 mm) to 1 3/4 in (45 mm), with the option for special door preparations enabling thicker panels from 1 3/4 in (46 mm) to 2 1/4 in (57 mm). This versatile system accommodates door widths between 19 5/8 in and 35 3/8 in, ensuring a tailored fit for your project. Constructed from durable aluminum and suitable for ceiling mounting, the HAWA Variofold 80/H system promises both longevity and performance. For specialized applications, reach out to the Sliding Technical Team for assistance, providing a sketch or images to achieve your desired end result.
HAWA Variofold 80/H System for End Folding Partition Wall
Ship via: No UPS - Common Carrier Only
Brand: Hawa
Detailed Door Movement: End Folding
Door Material: Wood
Door Movement: Movable Wall
Door Thickness: 35 to 45 mm
Door Width: 500 to 900 mm
Length - Overall Dimensions: 19 ft 8 in*
Load Capacity: 176 lb*
Manufacturing Material: Aluminum
Number of Doors: 2 + 1
Overall Length: 6 000 mm
Product #: WEBKIT1216583
Product number: WEBKIT1216583
Product №: WEBKIT1216583
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Length: 6 000 mm
Track Material: Anodized Aluminum
Track Mounting: Ceiling Mount
Weight Capacity per Door: 80 kg
