Richelieu WEBKIT1216585 HAWA Variofold 80/H System for End Folding Partition Wall is an exceptional solution for managing space with style and efficiency. Designed to accommodate wood doors weighing up to 176 lb (80 kg), this system offers versatile functionality for both residential and commercial applications. The HAWA Variofold system eliminates the need for a bottom guide channel when using up to two folding panels, providing a clean aesthetic while maintaining ease of operation. For installations with multiple folding doors, a lower guide channel enhances stability, ensuring smooth performance. This system is compatible with door thicknesses ranging from 1 3/8 in (35 mm) to 1 3/4 in (45 mm), and with special preparation, can accommodate thicker panels up to 2 1/4 in (57 mm). Constructed from durable aluminum, the system supports bifolding movement and is ceiling-mounted for a streamlined appearance. With an overall length of 19 ft 8 in, it allows for flexible design configurations. Ideal for widths between 19 5/8 in and 35 3/8 in, the HAWA Variofold system is perfect for creating dynamic, functional spaces. For specialized applications or assistance, Richelieu’s Sliding Technical Team is readily available to help.
HAWA Variofold 80/H System for End Folding Partition Wall
Ship via: No UPS - Common Carrier Only
Brand: Hawa
Detailed Door Movement: End Folding
Door Material: Wood
Door Movement: Movable Wall
Door Thickness: 35 to 45 mm
Door Width: 500 to 900 mm
Length - Overall Dimensions: 19 ft 8 in*
Load Capacity: 176 lb*
Manufacturing Material: Aluminum
Number of Doors: 3 + 1
Overall Length: 6 000 mm
Product #: WEBKIT1216585
Product number: WEBKIT1216585
Product №: WEBKIT1216585
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Length: 6 000 mm
Track Material: Anodized Aluminum
Track Mounting: Ceiling Mount
Weight Capacity per Door: 80 kg
