Richelieu WEBKIT1216586 HAWA Variofold 80/H System for End Folding Partition Wall offers a robust solution for wood doors weighing up to 176 lb (80 kg) each. This system is designed for versatility, accommodating up to two folding panels without a bottom guide channel. For greater stability and functionality, a lower guide channel is available for multiple folding door panels, ensuring smooth operation and enhanced durability. The standard configuration supports door thicknesses from 1 3/8 in (35 mm) to 1 3/4 in (45 mm), while special door preparation allows for thicker panels ranging from 1 3/4 in (46 mm) to 2 1/4 in (57 mm). The system is particularly well-suited for bifolding applications, making it an excellent choice for both residential and commercial spaces. With a door width range of 19 5/8 in to 35 3/8 in, it can adapt to various project requirements. Constructed from high-quality aluminum, this ceiling-mounted track system not only ensures a sleek appearance but also guarantees long-lasting performance. For specialized applications or further assistance, you can reach out to Richelieu's Sliding Technical Team. Elevate your space with the Richelieu HAWA Variofold system, where functionality meets style.
HAWA Variofold 80/H System for End Folding Partition Wall
Ship via: No UPS - Common Carrier Only
Brand: Hawa
Detailed Door Movement: End Folding
Door Material: Wood
Door Movement: Movable Wall
Door Thickness: 35 to 45 mm
Door Width: 500 to 900 mm
Length - Overall Dimensions: 19 ft 8 in*
Load Capacity: 176 lb*
Manufacturing Material: Aluminum
Number of Doors: 4
Overall Length: 6 000 mm
Product #: WEBKIT1216586
Product number: WEBKIT1216586
Product №: WEBKIT1216586
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Track Length: 6 000 mm
Track Material: Anodized Aluminum
Track Mounting: Ceiling Mount
Weight Capacity per Door: 80 kg
