Richelieu WEBKIT1213683 CINETTO PS40.1 Coplanar Sliding SystemRichelieu WEBKIT1213683 CINETTO PS40.1 Coplanar Sliding System offers an innovative solution for handling large cabinet doors, supporting weights of up to 132 lb (60 kg) each. This flexible system accommodates one, two, or three wood doors, making it ideal for closets, pantries, and storage millwork in both residential and commercial applications. Designed with convenience in mind, the Cinetto PS40.1 features recessed mount hardware that is adjustable, ensuring a seamless fit for your specific needs. The integrated soft-close mechanism enhances usability by providing a gentle, controlled closure. Notably, no special cabinet fabrication is necessary, simplifying the installation process. Available in two attractive finishes-silver and stainless steel effect anodized aluminum-the system complements various design aesthetics. It accommodates doors with a thickness of 3/4 to 1 9/16 inches and a maximum height of 9 feet 10 inches, providing versatility for different cabinetry styles. The system is equipped with upper-positioned ball-bearing rollers for smooth operation, and it is recommended to use a door straightener to maintain rigidity. Choose Richelieu’s Cinetto PS40.1 for a reliable, stylish, and efficient sliding door solution that enhances any space.
CINETTO PS40.1 Coplanar Sliding System
Cinetto PS40.1 Coplanar Sliding System for large cabinet doors weighing up to 132 lb (60 kg) each.
Features:
- Flexible system for one, two, or three wood doors
- Recessed mount hardware, adjustable
- Soft-close mechanism included
- No special cabinet fabrication is required
- Two types of track finishes: silver and stainless steel effect anodized aluminum
- Optional B-moved electronic motor system sold separately
This is an ideal solution for closets, pantries, large storage millwork, and wardrobes/armoires in residential and commercial applications.
IMPORTANT: We recommend that you use a door straightener/stiffener to keep the door rigid.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Wardrobe, Pantry, Cabinet, Storage
Brand: CINETTO
Brand Model: Cinetto PS40
Door Height: 3 000 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Coplanar
Door Position: Full Overlay, Inset/Inlay
Door Thickness: Min. 19 mm
Door Thickness Including the Handle: 19 to 55 mm
Door Width: 888 to 1 800 mm
Finish: Satin Aluminum
Height Clearance: 131 mm
Length - Overall Dimensions: 96 1/2 in*
Load Capacity: 132 lb*
Manufacturing Material: Aluminum
Number of Doors: 1
Opening: Towards the right
Overall Length: 2 450 mm
PS40 Opening: Towards the right
Product #: WEBKIT1213683
Product number: WEBKIT1213683
Product №: WEBKIT1213683
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Length: 2 450 mm
Track Material: Anodized Aluminum
Track Mounting: Recessed - Inside Ceiling
Weight Capacity per Door: 45 to 100 kg
