Richelieu WEBKIT1214147 CINETTO PS40.2 Coplanar Sliding SystemRichelieu WEBKIT1214147 Cinetto PS40.2 Coplanar Sliding System offers an innovative solution for large cabinet doors, accommodating weights of up to 132 lb (60 kg) each. This flexible system can seamlessly handle one, two, or three wood doors, making it ideal for various applications such as wardrobes, pantries, and large storage millwork in both residential and commercial environments. Engineered for convenience, the Cinetto PS40.2 features adjustable surface mount hardware and comes with a soft-close mechanism, ensuring a smooth and quiet operation. Its design requires no special cabinet fabrication, simplifying installation. The system is available in two elegant track finishes-silver and stainless steel effect anodized aluminum-allowing for versatility in design aesthetics. The product supports door widths ranging from 35 to 70 7/8 inches and accommodates heights up to 9 feet 10 inches, making it suitable for larger spaces. It is crucial to use a door straightener or stiffener to enhance the rigidity of the doors. With a load capacity that ranges between 99.2 to 220 lb, the Richelieu Cinetto PS40.2 is a robust choice for those seeking functionality without compromising style.
CINETTO PS40.2 Coplanar Sliding System
Cinetto PS40.2 Coplanar Sliding System for large cabinet doors weighing up to 132 lb (60 kg) each.
Features:
- Flexible system for one, two, or three wood doors
- Surface mount hardware, adjustable
- Soft-close mechanism included
- No special cabinet fabrication is required
- Two types of track finishes: silver and stainless steel effect anodized aluminum
This is an ideal solution for closets, pantries, large storage millwork, and wardrobes/armoires in residential and commercial applications.
IMPORTANT: We recommend that you use a door straightener/stiffener to make the door more rigid.
Attributes
Ship via: No UPS - Common Carrier Only
" Optional" Door Width: 890 to 1 800 mm
Adjustable: Yes
Application: Wardrobe, Pantry, Cabinet, Storage
Brand: CINETTO
Brand Model: Cinetto PS40
Detailed Door Movement: Bypassing
Door Height: 3 000 mm
Door Material: Wood
Door Movement: Coplanar
Door Position: Full Overlay, Inset/Inlay
Door Thickness: Min. 19 mm
Door Thickness Including the Handle: 16 to 55 mm
Door Width: 888 to 1 800 mm
Finish: Satin Aluminum
Height Clearance: 131 mm
Length - Overall Dimensions: 96 1/2 in*
Load Capacity: 99.2 to 220 lb*
Manufacturing Material: Aluminum
Number of Doors: 2
Opening: Towards the right / Towards the left
Overall Length: 2 450 mm
PS40 Opening: Towards the left / Towards the right
Product #: WEBKIT1214147
Product number: WEBKIT1214147
Product №: WEBKIT1214147
Roller Position: Upper
Roller Type: Ball Bearing
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Material: Anodized Aluminum
Weight Capacity per Door: 60 kg
