Richelieu WEBKIT1214440 HAWA CLIPO 36 H IS Bypassing Sliding Door System offers a sophisticated solution for sliding wood doors, accommodating weights of up to 77 lb (36 kg). This top-sliding system is ideal for inslide/inset applications, seamlessly integrating into various spaces such as pantries, furniture, and cabinets. The innovative design features a running gear that is conveniently clipped into a 35 mm diameter housing located at the back of the door, allowing for easy adjustment with an Allen key. Users can choose from different top track options for both single and double track applications, which can be either recessed or surface mounted for added flexibility. Adding a unique touch, the system includes a spring-loaded lower guide wheel and guide rail insert system that adapts to the contours of the cabinet floor as the door glides smoothly across the cabinet face. The maximum door height is 86 5/8 inches, with a thickness range of 3/4 to 31/32 inches and a width limit of 39 3/8 inches. While the soft-close mechanism is available separately, the standard configuration ensures a reliable and efficient door operation for up to three doors. Elevate your cabinetry with Richelieu’s HAWA CLIPO 36 H IS.
HAWA CLIPO 36 H IS Bypassing Sliding Door System
Adjustable: Yes
Application: Pantry, Furniture, Cabinet
Brand: Hawa
Detailed Door Movement: Bypassing
Door Height: Max. 2 200 mm
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inset/Inlay
Door Thickness: 19 to 25 mm
Door Width: Max. 1 000 mm
Load Capacity: Max. 79.4 lb*
Number of Doors: 3
Product #: WEBKIT1214440
Product number: WEBKIT1214440
Product №: WEBKIT1214440
Roller Type: Axle (Bushing)
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Closing: No
Track Type: Single
Track type: Single
Weight Capacity per Door: Max. 36 kg
