Richelieu WEBKIT1224363 HAWA JUNIOR B Series Sliding Door System InstructionsRichelieu WEBKIT1224363 HAWA JUNIOR B Series Sliding Door System offers a sophisticated solution for both commercial and residential spaces, accommodating doors weighing between 88 lb to 550 lb (40 kg to 250 kg). This sliding door system features a low-profile rebate/mortise mount suspension plate that seamlessly integrates into the design, minimizing the gap between the door and the upper track, which eliminates the need for a fascia. Designed for versatility, the system includes various track options suitable for single sliding, biparting, and bypassing applications. The integrated track stopper, along with an adjustable retaining device, prevents door bounce-back, ensuring a smooth and quiet operation. Premium trolleys guarantee long-lasting performance, while the optional SoftMove soft/self-closing mechanism is available for doors weighing between 88 lb to 264 lb (40 kg to 120 kg). Ideal for room dividers, pocket doors, wall partitions, and low headroom applications, the HAWA JUNIOR B Series is compatible with doors that range in height from 59 to 118 inches and thickness from 1 3/16 to 1 25/32 inches. With a satin aluminum finish, this system combines functionality with modern aesthetics, making it a perfect choice for any interior design project.
HAWA JUNIOR B Series Sliding Door System
The HAWA JUNIOR B Series sliding wood door systems for doors weighing 88 lb to 550 lb (40 kg to 250 kg) per door.
- Low profile rebate/mortise mount suspension plate for the top of the door
- Minimal gap between the top of the door and upper track, does not require a fascia
- Integrated track stopper with adjustable retaining device to resist door bounce back
- Versatile track options in various lengths for single sliding, biparting, and bypassing applications
- Smooth and quiet premium performance and long-lasting trolleys
- Available SoftMove soft/self-closing mechanism sold separately for doors weighing from 88 lb to 264 lb (40 kg to 120 kg) per door
The HAWA JUNIOR B Series is an ideal solution for premium commercial and residential projects, room dividers, pocket doors, wall partitions, and low headroom applications.
Attributes
Ship via: No UPS - Common Carrier Only
Adjustable: Yes
Application: Standard Access Door
Brand: Hawa
Detailed Door Movement: Biparting
Door Height: Max. 3 000 mm
Door Installation: Top Hung
Door Material: Wood
Door Movement: Straight Sliding
Door Position: Inside Frame
Door Thickness: Min. 30 mm
Door Width: 830 to 1 000 mm
Finish: Satin Aluminum
Length - Overall Dimensions: 13 ft 1 in*
Load Capacity: 44.1 to 88.2 lb*
Number of Doors: 2
Overall Length: 4 m
Product #: WEBKIT1224363
Product number: WEBKIT1224363
Product №: WEBKIT1224363
Shipping Limitations: Some products exceed standard small package size regulations and may incur additional fees. Items measuring 84" or more could require extra charges or LTL shipping. Please keep this in mind when ordering, and contact customer service for more details.
Soft- Close Type: One-Way Operation
Soft- Closing: Yes
Track Finish: Satin Aluminum
Track Length: 4 m
Track Mounting: Ceiling Mount
Weight Capacity per Door: Max. 40 kg
